Lapp UNITRONIC LiYY Series Data Cable 7 Pairs 7 Cores 0.34 mm² 100 m Grey Sheath Polyvinyl Chloride 0028407
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 500V |
| Brand | Lapp |
| CROSS SECTIONAL AREA | 0.34mm² |
| Model | 0028407 |
| Cable Length | 100m |
| Series | UNITRONIC LiYY |
| Outside diameter | 5.9mm |
| Maximum Operating Temperature | 80°C |
| Number Of Cores | 7 |
| Conductor Material | Bare Copper |
| Minimum Operating Temperature | -40°C |
| Jacket Material | Polyvinyl Chloride |
| Standards/Approvals | IEC 60332-1-2 |
| Jacket Colour | Grey |
| Fire Behaviour | Flame Retardant |
| Conductor Type | Extra Fine |
| Number of Strands | 7 |
| Core Strands | 7 x 0.25mm |
| Size of Strands | 0.25mm |
| • Operating temperature with occasional flexing | -5°C to +70°C |
| Number of Pairs | 7 |
| • Operating temperature in fixed installation | -40°C to +80°C |
Key Features
- The cable has a grey polyvinyl chloride sheath providing flame retardant properties.
- It features an outside diameter of 5.9 mm enabling space-saving installations.
- Designed for operating voltages up to 500V with high-quality bare copper conductor material.
- Suitable for use in dry or damp indoor environments with operating temperatures from -40°C to +80°C.
- Meets IEC 60332-1-2 flame retardant standard ensuring safety in industrial applications.
- Each conductor is made of 7 strands of 0.25 mm extra fine bare copper wire for optimal conductivity.
- Perfect for control, signal, and process equipment requiring multi-core data cables.
- The cable employs a clear color coding system for ease of installation and maintenance.
Product Description
Lapp 0028407 UNITRONIC LiYY Series Data Cable delivers reliable performance with 7 pairs (7 cores) of conductors having a 0.34 mm² cross-sectional area. It is 100 meters in length with a compact 5.9 mm outside diameter, making it ideal for installations requiring space efficiency.
The cable features a grey sheath made from polyvinyl chloride (PVC), providing flame retardant properties in accordance with IEC 60332-1-2 standards. The conductors are composed of extra fine bare copper strands (7 strands of 0.25 mm each) to ensure excellent electrical conductivity and rapid signal transmission up to a voltage rating of 500V.
This data cable is designed for multi-functional use in control and signal transmission applications across industrial, office, and laboratory environments. Its robust build allows safe use in dry or damp indoor conditions with operating temperatures ranging from -40°C to +80°C for fixed installations and occasional flexing rated from -5°C to +70°C.
The flame retardant design enhances safety by limiting fire spread, suited for rigorous industrial use cases such as process control equipment, industrial computers, and measuring instruments. The cable also features a DIN color-coded system to facilitate straightforward installation and troubleshooting.
Accessories compatible with this cable include Lapp cable glands like the Skintop series, which provide secure and easy cable entry solutions meeting IP68 protection standards. The cable has a grey polyvinyl chloride sheath providing flame retardant properties.
It features an outside diameter of 5.9 mm enabling space-saving installations. Designed for operating voltages up to 500V with high-quality bare copper conductor material. Suitable for use in dry or damp indoor environments with operating temperatures from -40°C to +80°C.
Meets IEC 60332-1-2 flame retardant standard ensuring safety in industrial applications. Each conductor is made of 7 strands of 0.25 mm extra fine bare copper wire for optimal conductivity. Perfect for control, signal, and process equipment requiring multi-core data cables.
The cable employs a clear color coding system for ease of installation and maintenance. Recommended for industrial computers, office machines, and measuring equipment applications. Explore EnvMart's extensive range of electrical and automation cables to find the perfect Data Cable solution for your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is designed for operating voltages up to 500V.
The outside diameter of this cable is 5.9 mm, allowing for space-saving installations.
It can operate in fixed installations at temperatures ranging from -40°C to +80°C.
This cable features 7 cores, making it suitable for various applications.
The conductors are made of extra fine bare copper, consisting of 7 strands of 0.25 mm each for optimal conductivity.
It meets the IEC 60332-1-2 flame retardant standard, enhancing safety in industrial applications.
The cable has a length of 100 meters.
The minimum operating temperature for this model is -40°C.
Yes, it is suitable for use in dry or damp indoor environments.
It is recommended for control, signal, and process equipment in industrial, office, and laboratory environments.
The jacket is made from polyvinyl chloride (PVC), providing flame retardant properties.
Compatible accessories include Lapp cable glands like the Skintop series, which provide secure cable entry solutions.
