ABB Tmax XT Molded Case Circuit Breaker 4-Pole 160A 65kA Breaking Capacity Fixed 1SDA067107R1 XT2N 160 Ekip LSI 160A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 160A 65kA Breaking Capacity Fixed 1SDA067107R1 XT2N 160 Ekip LSI 160A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067107R1 XT2N 160 Ekip LSI 160A FF
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	160A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	65kA
Number of Poles	4
Standards/Approvals	RoHS, CE, IEC
Rated AC Voltage	690V ac
Tripping Mechanism	Solid State
Reset Actuator Type	Lever

Key Features

The breaker supports a current rating of 160A for demanding electrical applications.
It features a 4-pole configuration suitable for complex systems requiring neutral conductor protection.
Fixed mounting style ensures enhanced installation stability and reliability.
Toggle switch reset actuator allows quick and easy manual resetting after a trip.
Solid state tripping mechanism provides precise overload and fault protection.
Bolt terminal contacts ensure secure and reliable electrical connections.
Designed for industrial and automation applications requiring high breaking capacity.
Complies with RoHS, CE, and IEC standards for safety and performance.

Product Description

ABB 1SDA067107R1 XT2N 160 Ekip LSI 160A FF Molded Case Circuit Breaker from the Tmax XT range is a 4-pole, fixed mounting breaker rated at 160A with a breaking capacity of 65kA at a maximum rated AC voltage of 690V. It is designed for robust circuit protection in industrial environments, automation systems, and custom electrical panels.

This breaker employs a solid state tripping mechanism combined with a toggle switch reset actuator for simple operation and reliable disruption management. The 4-pole configuration provides comprehensive protection covering all phases and the neutral conductor, essential for balanced electrical loads.

The fixture uses bolt terminal contacts to guarantee secure electrical connections, enhancing system stability in demanding applications. Its construction complies with RoHS, CE, and IEC standards, assuring safety and environmental compliance. With a compact form factor measuring 130mm high, 120mm wide, and 82.5mm depth, this breaker fits suitably in various electrical panels.

The 1SDA06 series is optimized for use in industrial facilities, automation systems, and complex electrical infrastructures where precise overload protection and high fault breaking capacity are paramount. Its fixed mounting ensures stable installation in diverse electrical setups.

The breaker supports a current rating of 160A for stable, high-capacity circuit management. High breaking capacity up to 65kA meets stringent industrial protection requirements. Fixed mount style prevents movement and enhances breaker lifespan under heavy use.

Lever-type toggle switch allows effortless resetting after faults or overload trips. Solid state tripping mechanism enhances protection accuracy and response time. Bolt terminal contacts provide reliable and secure electrical connectivity.

Compact dimensions allow integration into various panel types without space issues. Compliant with international standards for quality and safety assurance.

This ABB Molded Case Circuit Breaker is essential equipment for maintaining safety and operational continuity in industrial and commercial electrical systems. Explore the full range of ABB MCCBs for suitable options in your electrical protection projects.
