ABB Tmax XT Molded Case Circuit Breaker 3-Pole 32A Breaking Capacity 150 kA Fixed 1SDA067786R1 XT2L 160 MA 32 FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 32A Breaking Capacity 150 kA Fixed 1SDA067786R1 XT2L 160 MA 32 FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067786R1 XT2L 160 MA 32 FF
Depth	82.5mm
Width	90mm
Mount Type	Fixed
Current Rating	32A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	3
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Magnetic
Reset Actuator Type	Lever
Rated current (In)	32 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Designed for industrial and commercial electrical protection applications.
Features thermomagnetic release and magnetic tripping mechanism.
Rated AC voltage is 690V and rated DC voltage is 500V.
Compact dimensions with height 130mm, width 90mm, and depth 82.5mm.
Front fixed terminals ensure secure and stable connections.
Complies with RoHS, IEC, and CE standards.
Efficient lever type reset actuator for easy operation.
Designed and manufactured in Italy ensuring quality and reliability.

Product Description

ABB 1SDA067786R1 XT2L 160 MA 32 FF Molded Case Circuit Breaker is a robust and reliable electrical protection device designed for industrial, commercial, and manufacturing environments. It features a 3-pole configuration suitable for protecting circuits with a rated current of 32 amperes. The breaker is fixed mount type with front terminals, ensuring easy installation and secure connection in distribution panels.

This model is part of the Tmax XT series by ABB, known for high breaking capacity of 150 kiloamperes and rated for AC voltage up to 690 volts and DC voltage up to 500 volts. Its thermomagnetic release mechanism combines thermal protection against overloads and magnetic tripping for short circuits, providing comprehensive circuit protection. The lever type reset actuator allows for smooth and easy resetting after tripping events.

The compact design with dimensions of 130mm height, 90mm width, and 82.5mm depth makes it suitable for various panel sizes while maintaining high performance. Certified to international standards RoHS, IEC, and CE, this breaker meets stringent quality and safety requirements. It is also a Better World product designed for disassembly, supporting sustainability by facilitating recycling at end of life.

3-pole molded case circuit breaker suitable for industrial electrical systems. 32A rated current with high breaking capacity of 150 kA for reliable fault interruption. Fixed mount and front terminal connection for secure installation.

Thermomagnetic trip mechanism with magnetic tripping for overload and short circuit protection. Rated voltage: 690V AC and 500V DC with 8kV impulse withstand voltage. Compact size and lever type reset actuator for ease of use.

Certified to RoHS, IEC, and CE standards ensuring environmental and safety compliance. Manufactured in Italy with high quality standards. Designed for disassembly, supporting sustainability goals in electrical equipment.

This ABB Molded Case Circuit Breaker finds applications in electrical distribution systems across industrial plants, manufacturing facilities, commercial buildings, and utility operations. It offers reliable protection against electrical faults, ensuring operational continuity and safety.

Explore the range of ABB electrical protection devices and circuit breakers on EnvMart to enhance your electrical safety and system reliability.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The breaking capacity of this molded case circuit breaker is 150 kA, allowing it to effectively interrupt fault currents.

This model has a rated current of 32A, making it suitable for various industrial and commercial applications.

The dimensions of this unit are 130mm in height, 90mm in width, and 82.5mm in depth, allowing for compact installation.

It features a thermomagnetic tripping mechanism that provides protection against overloads and short circuits.

The rated AC voltage is 690V and the rated DC voltage is 500V, making it versatile for different electrical systems.

This model supports fixed mounting, ensuring secure installation in electrical distribution panels.

It complies with RoHS, IEC, and CE standards, ensuring it meets environmental and safety requirements.

The rated impulse withstand voltage is 8 kV, providing additional protection against voltage surges.

It features a lever type reset actuator, allowing for smooth and easy resetting after a tripping event.

This product is manufactured in Italy, ensuring adherence to high quality standards.

This model is part of the Tmax XT series by ABB, known for its robust electrical protection capabilities.

It is suitable for use in industrial plants, manufacturing facilities, commercial buildings, and utility operations, providing reliable protection against electrical faults.
