ABB Tmax XT Molded Case Circuit Breaker, 3-Pole, 16A, Breaking Capacity 65 kA, Fixed Mount 1SDA067716R1 XT2N 160 TMG 16A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker, 3-Pole, 16A, Breaking Capacity 65 kA, Fixed Mount 1SDA067716R1 XT2N 160 TMG 16A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067716R1 XT2N 160 TMG 16A FF
Depth	82.5mm
Width	90mm
Mount Type	Fixed
Current Rating	16A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	65kA
Number of Poles	3
Standards/Approvals	RoHS, CE, IEC
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	16 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Designed with a fixed mounting type for secure installation.
Equipped with a thermal magnetic tripping mechanism for precise circuit protection.
Suitable for use with rated AC voltage of 690V and DC voltage of 500V.
Complies with RoHS, CE, and IEC standards for safety and quality assurance.
Front terminal design ensures ease of wiring and maintenance.
Compact dimensions of 130mm height, 90mm width, and 82.5mm depth optimize panel space.
Incorporates a lever-style reset actuator for quick manual reset after tripping.
High impulse withstand voltage rating of 8 kV enhances durability.

Product Description

ABB 1SDA067716R1 XT2N 160 TMG 16A FF Molded Case Circuit Breaker provides robust and precise protection for electrical installations, suitable for industrial, commercial, and electrical automation applications. This 3-pole breaker supports a current rating of 16 amperes and has an impressive breaking capacity of 65 kiloamperes, ensuring reliable interruption of fault currents.

The device features a fixed mounting design with front terminals, enabling secure installation and straightforward wiring. Its thermal magnetic tripping mechanism offers enhanced safety by protecting circuits from overloads and short circuits effectively. Rated for 690V AC and 500V DC, it is versatile for diverse electrical systems.

Compliant with international standards including RoHS, CE, and IEC, this molded case circuit breaker guarantees quality and operational safety. The breaker’s compact dimensions (130mm height, 90mm width, 82.5mm depth) allow efficient use of panel space without compromising performance. Its lever-type reset actuator ensures convenient manual reset following any trip event.

Additionally, the breaker can withstand impulse voltages up to 8 kV, providing durability against transient electrical surges. Manufactured in Italy, this product represents ABB’s commitment to high-quality electrical components. Ideal for use in industrial electrical systems, construction projects, manufacturing plants, and electrical distribution networks.

Designed with a fixed mounting type for secure installation. Equipped with a thermal magnetic tripping mechanism for precise circuit protection. Suitable for use with rated AC voltage of 690V and DC voltage of 500V. Complies with RoHS, CE, and IEC standards for safety and quality assurance.

Front terminal design ensures ease of wiring and maintenance. Compact dimensions optimize panel space with height 130mm, width 90mm, and depth 82.5mm. Incorporates a lever-style reset actuator for quick manual reset after tripping.

High impulse withstand voltage rating of 8 kV enhances durability. Country of origin is Italy, ensuring premium manufacturing quality.
