ABB Tmax XT Molded Case Circuit Breaker 4-Pole 25A 690V AC 500V DC Thermal Magnetic Tripping 1SDA067617R1 XT2H 160 TMD 25A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 25A 690V AC 500V DC Thermal Magnetic Tripping 1SDA067617R1 XT2H 160 TMD 25A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067617R1 XT2H 160 TMD 25A FF
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	25A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	100kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	25 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Features thermal magnetic tripping mechanism for reliable protection.
Supports rated AC voltage up to 690V and DC voltage up to 500V.
Includes fixed terminal and mount type for secure installation.
Constructed with a height of 130mm, width of 120mm, and depth of 82.5mm for compact fitting.
Complies with CE, IEC, and RoHS standards for quality and safety.
Equipped with a lever reset actuator for easy operation.
Designed for disassembly supporting environmental sustainability.
Operates at rated frequency 50/60 Hz suitable for varied electrical systems.

Product Description

ABB 1SDA067617R1 XT2H 160 TMD 25A FF Molded Case Circuit Breaker is engineered for industrial and commercial electrical protection requiring reliable interruption of circuits. This 4-pole circuit breaker provides a current rating of 25 A and a high breaking capacity of 100 kA ensuring safe disconnection under fault conditions.

The breaker supports rated AC voltage of up to 690 V and DC voltage up to 500 V. It features thermal magnetic tripping mechanism which combines precise thermal and magnetic protection features suitable for various electrical load types. The fixed terminal and fixed mount type simplify installation in distribution boards or panels.

Physical dimensions measuring 130 mm in height, 120 mm in width, and 82.5 mm in depth make it suitable for compact electrical enclosures. Compliant with CE, IEC, and RoHS standards, this product assures high safety, environmental compliance, and quality assurance.

The reset actuator is a lever type which facilitates manual resetting post trip event. Additionally, the product is designed for disassembly providing an environmentally responsible lifecycle advantage.

Operating on rated frequency of 50/60 Hz, it accommodates different power systems internationally. The circuit breaker is manufactured in Italy, reflecting trusted European quality and standards.

Features thermal magnetic tripping mechanism for reliable protection. Supports rated AC voltage up to 690V and DC voltage up to 500V. Includes fixed terminal and mount type for secure installation. Complies with CE, IEC, and RoHS standards for quality and safety.

Compact size suitable for tight electrical enclosures. Lever reset actuator for easy operation. Designed for disassembly supporting environmental sustainability. Rated frequency of 50/60 Hz for flexible use.

This ABB Molded Case Circuit Breaker is ideal for applications in industrial control panels, automation systems, electrical distribution boards, and other electrical infrastructure requiring robust overcurrent protection. EnvMart offers a comprehensive selection of MCCBs including this reliable ABB model.
