ABB XT2L Molded Case Circuit Breaker 3-Pole 2A 690V AC 150kA Breaking Capacity Thermal Magnetic Tripping Lever Italy XT2L

Free Delivery in India | Lowest Global Shipping Charges

ABB XT2L Molded Case Circuit Breaker 3-Pole 2A 690V AC 150kA Breaking Capacity Thermal Magnetic Tripping Lever Italy XT2L



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT2L
Brand	ABB
Height	130mm
Model	XT2L
Depth	82.5mm
Width	90mm
Mount Type	Fixed
Current Rating	2A
Series	XT2L
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	3
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Short circuit performance level	L

Key Features

Equipped with thermal magnetic tripping mechanism for enhanced safety.
Fixed mounting type with front terminals for secure installation.
Compact dimensions of 130mm height, 90mm width, and 82.5mm depth.
Designed for industrial and commercial power distribution applications.
Constructed according to CE, IEC, and RoHS standards.
Lever-type reset actuator for easy manual reset after tripping.
Provides short circuit performance level L with 20A rated instantaneous short circuit setting.
Rated DC voltage of 500V suitable for DC applications.

Product Description

ABB XT2L Molded Case Circuit Breaker is a high-performance 3-pole circuit breaker designed for effective power distribution and protection in industrial and commercial electrical systems. It supports a rated AC voltage of 690V and a current rating of 2A, delivering robust protection in demanding environments.

This model features a thermal magnetic tripping mechanism, which offers rapid interruption of current under fault conditions, enhancing electrical safety and protecting connected equipment. The breaker has a fixed mounting type with front terminal connections, ensuring a secure and stable installation.

Compact and space-saving, the device has dimensions of 130mm in height, 90mm in width, and 82.5mm in depth. It complies with international standards including CE, IEC, and RoHS, ensuring environmental and safety compliance.

The reset actuator is lever operated, enabling easy manual reset after the breaker trips, facilitating quick restoration of service. Additionally, the breaker is rated for a breaking capacity of 150kA, capable of interrupting high fault currents to prevent equipment damage.

Rated for both AC (690V) and DC (500V) voltages, the ABB XT2L breaker offers wide application versatility. It supports a short circuit performance level of L and includes a 20A rated instantaneous short circuit setting, providing precise protection tuned to specific system requirements.

Manufactured in Italy, the product reflects ABB's commitment to quality and manufacturing excellence. This molded case circuit breaker is suitable for various industrial, manufacturing, electrical distribution, and commercial applications requiring reliable circuit protection.

Equipped with thermal magnetic tripping mechanism for enhanced safety. Fixed mounting type with front terminals for secure installation. Compact dimensions of 130mm height, 90mm width, and 82.5mm depth. Designed for industrial and commercial power distribution applications.

Constructed according to CE, IEC, and RoHS standards. Lever-type reset actuator for easy manual reset after tripping. Provides short circuit performance level L with 20A rated instantaneous short circuit setting. Rated DC voltage of 500V suitable for DC applications.

Manufactured in Italy ensuring high quality and durability. Browse the Molded Case Circuit Breaker category for more high-quality ABB electrical protection devices on EnvMart.
