ABB Molded Case Circuit Breaker 3-Pole 100A Breaking Capacity 150 kA Fixed Mount XT4L 1SDA06

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 3-Pole 100A Breaking Capacity 150 kA Fixed Mount XT4L 1SDA06



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT4L
Brand	ABB
Height	160mm
Model	XT4L
Depth	82.5mm
Width	105mm
Mount Type	Fixed
Current Rating	100A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	3
Standards/Approvals	RoHS, CE, IEC
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Short circuit performance level	L

Key Features

Rated operational voltage of 690V ac ensures reliable performance.
Solid state tripping mechanism provides precise protection.
Lever type reset actuator allows easy manual operation.
Complies with RoHS, CE, and IEC standards for quality assurance.
Compact dimensions of 105mm width, 160mm height, and 82.5mm depth optimize panel space.
Suitable for industrial, commercial, and electrical automation applications.
Designed with environmental sustainability in mind featuring disassembly capability.
3 poles provide efficient protection for three-phase circuits.

Product Description

ABB XT4L 1SDA06 Molded Case Circuit Breaker is a 3-pole fixed mount electrical protection device with a current rating of 100A and breaking capacity of 150kA. Engineered for industrial and commercial electrical systems, it offers reliable short circuit and overload protection.

This circuit breaker supports a rated operational voltage of 690V ac and an insulation rating of 1000V. Its solid state release Ekip LS/I ensures rapid and accurate tripping performance adapting to varying electrical loads.

The reset actuator is lever type, enabling user-friendly manual reset functionality after a trip event. With compliance to IEC, RoHS, and CE standards, it assures high safety and environmental requirements. Its design incorporates the Better World Claim of being designed for disassembly and sustainability.

The compact dimensions of 105mm width, 160mm height, and 82.5mm depth allow for optimized installation within electrical panels and switchgear assemblies. Fixed terminals provide secure and stable wire connections.

Its short circuit performance level is classified as L, suitable for demanding circuit protection scenarios in manufacturing plants, HVAC systems, and electrical distribution centers.

This product is manufactured in Italy, reflecting ABB's commitment to quality and reliability in electrical protection equipment. Rated current of 100A with 3 poles for three-phase systems. Breaking capacity up to 150kA for high fault current interruption.

Solid state tripping mechanism ensures precise and fast release. Lever reset actuator for manual reset convenience. Compact form factor fits standard industrial electrical panels. Compliance with RoHS, CE, IEC standards for safety and environment.

Designed for disassembly supporting environmental sustainability. Fixed mounting and terminal design for durable installation. Typical use in industrial, commercial, and automation electrical systems. Explore more reliable circuit protection solutions and related electrical components with EnvMart for your industrial, manufacturing, and commercial applications.
