ABB Tmax XT Molded Case Circuit Breaker 3-Pole 40A 690V AC 100kA Breaking Capacity 1SDA068511R1 XT4H 160 Ekip LS/I 40A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 40A 690V AC 100kA Breaking Capacity 1SDA068511R1 XT4H 160 Ekip LS/I 40A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	160mm
Model	1SDA068511R1 XT4H 160 Ekip LS/I 40A FF
Depth	82.5mm
Width	105mm
Mount Type	Fixed
Current Rating	40A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	100kA
Number of Poles	3
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Rated current (In)	40 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Offers fixed mounting type suitable for robust installations.
Operates at rated AC voltage of 690V AC and frequency of 50/60 Hz.
Equipped with solid state tripping mechanism ensuring precise circuit protection.
Features front fixed terminals for secure connection.
Includes lever-type reset actuator for easy manual reset.
Manufactured in Italy, adhering to IEC, CE, and RoHS standards.
Designed for disassembly supporting better world sustainability initiatives.

Product Description

ABB 1SDA068511R1 XT4H 160 Ekip LS/I 40A FF Molded Case Circuit Breaker is a high-performance 3-pole MCCB designed primarily for industrial and commercial electrical circuit protection. Its fixed mounting type and front terminal configuration provide secure and reliable installation in power distribution panels.

Rated for a continuous current of 40A, it supports a rated AC voltage of 690V AC and operates effectively within 50/60 Hz frequency ranges. The circuit breaker delivers an impressively high breaking capacity of 100kA, making it suitable for handling short circuit conditions safely.

The solid state tripping mechanism integrated ensures rapid and stable response to electrical faults, minimizing damage to the system. The lever reset actuator enables easy manual reset following a trip event, enhancing usability.

Compactly engineered with a height of 160mm, width of 105mm, and depth of 82.5mm, this device fits seamlessly into standard MCCB enclosures. Meeting international standards including IEC, CE, and RoHS further endorses its compliance and quality.

Manufactured in Italy under ABB’s Tmax XT range, this circuit breaker is part of the Better World product line, designed for disassembly to promote sustainable practices. It is ideally suited for electrical distribution, automation, manufacturing, and commercial power management applications.

Offers fixed mounting with front terminals ensuring secure electrical connections. Solid state tripping mechanism provides enhanced protection and reliability. Complies with IEC, CE, and RoHS standards ensuring safety and environmental adherence.

Designed for sustainability and ease of disassembly under ABB's Better World initiative. Compact dimensions facilitate integration in standard circuit breaker panels.

This ABB Molded Case Circuit Breaker is a precise and durable solution for controlling and safeguarding electrical circuits in industrial and commercial power systems. Find more top-quality ABB electrical protection devices in the EnvMart catalog.
