ABB Tmax XT Molded Case Circuit Breaker 4-Pole 40A 85kA Breaking Capacity Fixed Mount 1SDA068496R1 XT4S 160 Ekip I 40A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 40A 85kA Breaking Capacity Fixed Mount 1SDA068496R1 XT4S 160 Ekip I 40A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	160mm
Model	1SDA068496R1 XT4S 160 Ekip I 40A FF
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	40A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	85kA
Number of Poles	4
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Rated current (In)	40 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Rated AC voltage of 690V ensures high voltage protection.
Breaking capacity of 85 kA provides robust short circuit interruption.
Solid state tripping mechanism with lever reset actuator for reliable operation.
Complies with RoHS, IEC, and CE standards ensuring safety and quality.
Designed and manufactured in Italy for quality assurance.
Rated frequency supports both 50Hz and 60Hz power grids.
Better World product with design for disassembly supporting sustainability.
Front terminal type fixed for ease of installation.

Product Description

ABB 1SDA068496R1 XT4S 160 Ekip I 40A FF Molded Case Circuit Breaker is a premium 4-pole fixed mount electrical protection device suitable for industrial, commercial, and manufacturing environments. It is designed to safely interrupt circuits with a rated current of 40 amperes and withstand short circuit conditions up to 85 kA. Supporting a rated AC voltage of 690 volts and operating at both 50 and 60 Hz frequencies, this circuit breaker ensures reliable power management in diverse electrical systems.

The device features a solid state tripping mechanism with a lever reset actuator, offering quick and dependable fault response. It includes front fixed terminals facilitating secure and straightforward wiring. The compact size of 160mm height, 140mm width, and 82.5mm depth allows efficient panel integration without compromising performance.

Manufactured in Italy, the product complies with stringent RoHS, IEC, and CE standards, emphasizing safety and environmental responsibility. The Better World designation highlights its design for disassembly, supporting sustainable practices and easier recycling.

This Molded Case Circuit Breaker finds extensive applications in electrical distribution panels for industrial, manufacturing, HVAC, and commercial power systems requiring high breaking capacity and precision in circuit protection.

Rated current of 40 A for effective electrical protection. Breaking capacity of 85 kA to handle high fault currents. Compliance with international safety and environmental standards. Compact and ergonomic design optimized for installation space.

Front terminal fixed type ensures secure electrical connections. Solid state tripping mechanism ensures rapid fault detection and response. Supports rated voltage up to 690 V AC at 50/60 Hz frequency. Italian origin ensuring manufacturing quality and reliability.

Better World sustainability claim with designed for disassembly. Explore the extensive range of industrial circuit breakers, including ABB's Tmax XT series, on EnvMart for reliable and high-performance electrical protection solutions.
