ABB Tmax XT Molded Case Circuit Breaker 3-Pole 125A 150kA Breaking Capacity Fixed Mount 690V 1SDA068458R1 XT4L 160 MA 125 FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 125A 150kA Breaking Capacity Fixed Mount 690V 1SDA068458R1 XT4L 160 MA 125 FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	160mm
Model	1SDA068458R1 XT4L 160 MA 125 FF
Depth	82.5mm
Width	105mm
Mount Type	Fixed
Current Rating	125A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	3
Standards/Approvals	IEC, RoHS, CE
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Magnetic
Reset Actuator Type	Lever
Rated current (In)	125 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Operates at a rated AC voltage of 690 V and a rated DC voltage of 500 V.
Features a fixed mounting type with fixed terminals for secure installation.
Equipped with magnetic tripping mechanism and lever reset actuator for precise protection.
Designed with a compact form factor of 105mm width, 160mm height, and 82.5mm depth.
Complies with IEC, RoHS, and CE standards ensuring quality and safety.
Suitable for industrial and commercial electrical distribution applications.
Rated for uninterrupted current of 160 A and rated frequency of 50/60 Hz.
Manufactured in Italy ensuring high build quality and durability.

Product Description

ABB 1SDA068458R1 XT4L 160 MA 125 FF Molded Case Circuit Breaker is a high-performance electrical device designed for safe and efficient circuit protection in industrial, commercial, and manufacturing installations. It features a 3-pole configuration with a current rating of 125 A and a breaking capacity of 150 kA, suitable for demanding electrical distribution systems.

This circuit breaker operates at a rated AC voltage of 690 V and rated DC voltage of 500 V, with a rated frequency of 50/60 Hz, making it compatible with a wide range of electrical supply systems. The fixed mounting ensures secure installation and stable operation over time.

The device's magnetic tripping mechanism provides reliable and quick response against fault currents, minimizing equipment damage and downtime. The lever reset actuator allows easy manual resetting after tripping events. It complies with international IEC, RoHS, and CE standards assuring high safety and environmental compliance.

Its compact dimensions (105mm width, 160mm height, and 82.5mm depth) enable flexible integration in panel boards and switchgear. Designed for disassembly as part of ABB's Better World initiative, it supports sustainability and recycling goals.

Operates with rated uninterrupted current of 160 A. Comes with fixed terminals for front connection and secure wiring. Tripping mechanism type: Magnetic. Reset actuator type: Lever. Breaking capacity: 150 kA. Mount type: Fixed.

Standards met: IEC, RoHS, CE. Manufactured in Italy ensuring premium quality.

Suitable for electrical, industrial automation, commercial building installations, and HVAC applications requiring dependable circuit protection. This ABB Tmax XT Molded Case Circuit Breaker is a trusted choice for enhancing electrical system safety and reliability.
