ABB Tmax XT Molded Case Circuit Breaker 4-Pole 125A 690V AC 500V DC Thermal Magnetic 1SDA068355R1 XT4H 160 TMA 125A 3P+N FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 125A 690V AC 500V DC Thermal Magnetic 1SDA068355R1 XT4H 160 TMA 125A 3P+N FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	160mm
Model	1SDA068355R1 XT4H 160 TMA 125A 3P+N FF
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	125A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	100kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	125 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Features 4 poles for comprehensive circuit management.
Rated current of 125 amps suitable for high-performance applications.
Breaking capacity of 100 kA ensures safe interruption of fault currents.
Operates at rated AC voltage of 690V and DC voltage rating of 500V.
Compact dimensions with 160mm height, 140mm width, and 82.5mm depth.
Equipped with a lever reset actuator for easy manual operation.
Constructed according to CE, IEC, and RoHS standards for quality assurance.
Designed for disassembly to support sustainability initiatives.

Product Description

ABB 1SDA068355R1 XT4H 160 TMA 125A 3P+N FF Molded Case Circuit Breaker is a high-performance circuit protection device designed for industrial and commercial electrical systems. It supports rated AC voltages up to 690V and rated DC voltages up to 500V, making it versatile for various power distribution applications.

This 4-pole breaker features a thermal magnetic tripping mechanism combined with a fixed mounting type to provide rapid and reliable protection against overloads and short circuits. The breaker includes a lever reset actuator, allowing for straightforward manual operation in maintenance and system reset procedures.

Its breaking capacity of 100 kA ensures the safe interruption of fault currents, preventing damage to electrical infrastructure and enhancing safety in industrial environments. The device complies with international standards including CE, IEC, and RoHS, ensuring adherence to global quality and environmental regulations.

Compact with dimensions of 160mm height, 140mm width, and 82.5mm depth, it is designed for efficient panel integration. Additionally, the breaker supports sustainability through its designed-for-disassembly feature, aligning with green engineering practices.

Made in Italy, it reflects high European manufacturing standards and quality control. Ideal for use in industrial, manufacturing, electrical distribution, and automation systems. Features 4 poles for comprehensive circuit management.

Rated current of 125 amps suitable for high-performance applications. Breaking capacity of 100 kA ensures safe interruption of fault currents. Operates at rated AC voltage of 690V and DC voltage rating of 500V. Compact dimensions with 160mm height, 140mm width, and 82.5mm depth.

Equipped with a lever reset actuator for easy manual operation. Constructed according to CE, IEC, and RoHS standards for quality assurance. Designed for disassembly to support sustainability initiatives. Manufactured in Italy, ensuring European quality standards.
