ABB Molded Case Circuit Breaker 4-Pole 80A 690V AC 500V DC Thermal Magnetic Tripping Mechanism XT3S

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 80A 690V AC 500V DC Thermal Magnetic Tripping Mechanism XT3S



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT3S
Brand	ABB
Height	150mm
Model	XT3S
Depth	70mm
Width	140mm
Mount Type	Fixed
Current Rating	80A
Series	XT3S
Setting Range	56...80 A
Terminal type	Fixed
Breaking Capacity	85kA
Number of Poles	4
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Short circuit performance level	S
Release Type	TM

Key Features

Rated for 690V AC and 500V DC operational voltage.
High breaking capacity of 85 kA ensures enhanced safety.
Compact dimensions with 150mm height, 140mm width, and 70mm depth.
Designed with a lever reset actuator providing easy manual operation.
Complies with RoHS, IEC, and CE standards for quality assurance.
Better World product designed for disassembly to support sustainability.
Setting current range adjustable between 56 to 80 A.
Features fixed front terminal connections for secure wiring.

Product Description

ABB XT3S Molded Case Circuit Breaker with model code 1SDA068273R1 XT3S 250 TMG 80A FF is a high-quality 4-pole circuit breaker designed for industrial and commercial electrical protection. It supports high current ratings of 80 amperes and can operate at a rated AC voltage of 690V and a DC voltage of 500V, making it suitable for a variety of heavy-duty electrical applications. The device features a thermal magnetic (TMG) tripping mechanism for reliable trip performance under fault conditions.

The breaker has fixed mounting and fixed terminal types, ensuring robust installation and cable security. Its compact build with a height of 150mm, width of 140mm, and depth of 70mm facilitates straightforward integration into electrical panels and switchboards. The breaker also provides a high breaking capacity of 85 kA, enhancing system protection against short circuits and overloads.

Designed with environmental responsibility in mind, this ABB product is RoHS compliant and carries IEC and CE approvals. It is classified as a Better World product, emphasizing sustainability through design for disassembly. The lever-type reset actuator enables manual resetting, promoting ease of use in maintenance.

Additional technical details include a short circuit performance level of 'S', setting current adjustment range between 56 and 80 amperes, and an impulse withstand voltage rating of 8 kV. The product is manufactured in Italy, guaranteeing European quality standards.

This 4-pole molded case circuit breaker is an ideal choice for industrial, manufacturing, electrical panel assembly, infrastructure, and commercial power distribution applications, where reliable protection and operational safety are critical.

Rated operational voltage of 690V AC and 500V DC. 80A current rating with 85 kA breaking capacity. Compact footprint with 150mm height, 140mm width, and 70mm depth. Thermal magnetic tripping mechanism with a lever reset actuator.

Complies with RoHS, IEC, and CE standards.
