Schneider Electric Base for use with Quantum Automation Platform 206mm Width Telefast Series ABE7R16S210

Schneider Electric ABE7R16S210 base is a robust 16-channel electromechanical relay sub-base designed specifically for use with the Quantum Automation Platform. It features a width of 206mm and belongs to the Telefast series, providing a reliable removable terminal-block interface for PLC outputs in industrial automation systems.

Engineered for control applications, this base supports volt-free contacts, ensuring compatibility with a 24V DC supply commonly found in PLC environments. Each output channel handles currents up to 5A for preactuator connections, while maintaining a common current rating of 10A, suitable for higher load requirements.

With electrical durability rated for up to 500,000 switching cycles and an impressive mechanical life of 20,000,000 cycles, this base offers extensive operational longevity. It is designed to operate safely within a −5 to 60 °C temperature range, making it well-suited for diverse industrial settings.

Installation is flexible; the base can be mounted on a standard 35mm symmetrical DIN rail using clips or fixed on a solid plate with the supplied hardware. The assembly provides IP2X contact protection and withstands 750 °C incandescent wire tests while meeting pollution degree 2 standards, ensuring safety and reliability.

Electrical insulation rating includes a rated insulation voltage of 2,000V and an impulse withstand voltage of 2.5 kV in compliance with relevant standards. Terminal wiring is facilitated by removable terminal blocks with two terminals per channel, tightened with a flat Ø3.5mm screwdriver to a torque of 0.6 N·m.

Typical contact switching behaviour ensures response times of ≤10 milliseconds for energisation and ≤5 milliseconds for de-energisation with minimal contact bounce, maintaining control system responsiveness.

This base is ideal for replacing worn relay bases in Quantum PLC racks and expanding modular control systems requiring 16 discrete channels. Its use cases span industrial automation, control panels, manufacturing, and process control environments.

Provides a 16-channel electromechanical relay sub-base supporting discrete output control. Rated for 24V DC supply ensuring PLC-end compatibility. Supports maximum per-output common current of 10A and per-channel current of 5A for preactuator connections.

Electrical durability rated up to 500,000 cycles and mechanical life up to 20,000,000 cycles for long service intervals. Operates within a temperature range of −5 to 60 °C suitable for typical site environments. IP2X contact protection with resistance to 750 °C incandescent wire tests and pollution degree 2 compliance.

Mountable on 35mm symmetrical DIN rail or solid plate with supplied fixing kit for flexible installation. Typical switching times ≤10 ms for energisation and ≤5 ms for de-energisation with low contact bounce. Explore EnvMart's extensive range of Schneider Electric automation components and compatible Quantum series products for comprehensive industrial solutions.
