Schneider Electric ComPact NSXm Molded Case Circuit Breaker 3-Pole 32A 36kA Breaking Capacity DIN Rail LV426302
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426302 |
| Depth | 137mm |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 32A |
| Series | NSXm |
| Terminal type | Screw |
| Breaking Capacity | 36kA |
| Number of Poles | 3 |
| Standards/Approvals | RoHS, IEC, EN, EAC, CE, CCC |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Mount Hole Size | 4.5 mm |
Key Features
- ComPact NSXm is the smallest MCCB in the Compact NSX range, supporting 16 to 160 A applications.
- Equipped with a toggle switch reset actuator for easy operation.
- Tripping characteristics are Type D with a thermal magnetic tripping mechanism.
- Rated for 690 V AC voltage with screw terminal connections.
- Compact size with dimensions 137mm height, 80mm width, and 137mm depth.
- Meets multiple international standards including RoHS, IEC, EN, EAC, CE, and CCC.
- Mounting on DIN rail with mount hole size of 4.5 mm for secure installation.
Product Description
Schneider Electric LV426302 Molded Case Circuit Breaker belongs to the ComPact NSXm series, designed to provide reliable protection for electrical circuits up to 32A with a breaking capacity of 36 kA. This 3-pole MCCB is optimized for secure DIN rail mounting and offers excellent operational ease with its toggle switch reset actuator.
This compact MCCB fits versatile industrial, commercial, and residential applications, from low to medium power circuit protection, keeping installations safe from overloads and short circuits. Its thermal magnetic tripping mechanism ensures precise and fast response to fault currents.
The device is rated for use with 690 V AC voltage systems and features screw terminals for robust and lasting electrical connections. Constructed in compliance with various international standards including RoHS, IEC, EN, EAC, CE, and CCC, this circuit breaker ensures quality and safety assurance.
Measuring a compact 137mm in height and depth with a width of 80mm, it is engineered for space efficiency in panels and distribution boards. The DIN rail mount with a 4.5 mm mount hole size allows straightforward and secure installation.
Smallest size molded case circuit breaker in the Compact NSX range. Supports a range of current ratings from 16 to 160 A. Toggle switch reset actuator for easy manual control. Thermal magnetic trip mechanism with Type D tripping characteristics.
Rated for 690 V AC and 36 kA breaking capacity at 380/415 V. Complies with RoHS, IEC, EN, EAC, CE, and CCC standards. DIN rail mounting for convenient electrical panel integration.
This Molded Case Circuit Breaker is suitable for industrial automation, electrical distribution, and manufacturing environments where reliable circuit protection is critical. Its compact form factor allows for dense panel layouts while maintaining easy accessibility for maintenance. Schneider Electric's NSXm series continues to be trusted for performance and safety worldwide.
Explore similar Molded Case Circuit Breakers and circuit protection devices in EnvMart's Electronics & Electricals section.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this molded case circuit breaker is 36 kA.
It is rated for use with 690 V AC voltage systems.
This circuit breaker has 3 poles.
The dimensions are 137 mm in height, 80 mm in width, and 137 mm in depth.
It utilizes a thermal magnetic tripping mechanism.
The tripping characteristics are Type D.
It is designed for DIN rail mounting with a mount hole size of 4.5 mm.
It features a toggle switch reset actuator for easy operation.
It complies with RoHS, IEC, EN, EAC, CE, and CCC standards.
The current rating is 32 A.
The country of origin is India.
It is suitable for industrial automation, electrical distribution, and manufacturing environments.
