Schneider Electric ComPact NSXm Molded Case Circuit Breaker 4-Pole 16A 690V AC 25kA Thermal Magnetic LV426270
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426270 |
| Depth | 137mm |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 16A |
| Series | NSXm |
| Terminal type | Screw |
| Breaking Capacity | 25kA |
| Number of Poles | 4 |
| Standards/Approvals | IEC, EN, EAC, CE, CCC, RoHS |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Mount Hole Size | 4.5 mm |
Key Features
- This MCCB offers a current rating of 16A and rated AC voltage of 690V AC.
- It features a compact ComPact NSXm series design for versatile industrial and commercial electrical protection.
- Equipped with a toggle switch reset actuator for convenient operation.
- Includes Type D tripping characteristics to ensure precise thermal magnetic protection.
- Mount hole size is 4.5 mm for secure DIN Rail installation.
- Standards compliance includes IEC, EN, EAC, CE, CCC, and RoHS assuring quality and safety.
- Compact footprint measuring 80mm width, 137mm height and 137mm depth suitable for panel integration.
Product Description
Schneider Electric LV426270 ComPact NSXm Molded Case Circuit Breaker is a high-performance electrical protection device designed for industrial, commercial, and electrical automation applications. Rated at 16A current and 690V AC voltage, it provides reliable protection against overcurrent and short circuits with a breaking capacity of 25kA.
Part of the ComPact NSXm series, this compact MCCB is engineered to optimize space on DIN Rail mounting systems, providing ease of installation and maintenance. Its thermal magnetic tripping mechanism ensures quick response to electrical faults with type D trip characteristics suitable for motors and inductive loads.
The circuit breaker is equipped with screw-type terminals and a toggle switch reset actuator for secure and ergonomic operation. Dimensionally, it offers an 80mm width, and a height and depth of 137mm each, making it compatible with various electrical panel layouts.
Standards compliance with IEC, EN, EAC, CE, CCC, and RoHS certifies this product for global regulatory acceptance and environmental safety. Ideal for industrial plants, electrical distribution boards, HVAC systems, manufacturing facilities, and automated electrical systems.
This MCCB offers a current rating of 16A and rated AC voltage of 690V AC. It features a compact ComPact NSXm series design for versatile industrial and commercial electrical protection. Equipped with a toggle switch reset actuator for convenient operation.
Includes Type D tripping characteristics to ensure precise thermal magnetic protection. Mount hole size is 4.5 mm for secure DIN Rail installation. Standards compliance includes IEC, EN, EAC, CE, CCC, and RoHS assuring quality and safety.
Compact footprint measuring 80mm width, 137mm height and 137mm depth suitable for panel integration. Explore the full range of circuit breakers at EnvMart for enhanced electrical system safety and efficiency.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 16A.
It is rated for 690V AC.
The breaking capacity is 25kA.
This unit features 4 poles.
It measures 80mm in width, 137mm in height, and 137mm in depth.
It utilizes a thermal magnetic tripping mechanism.
It includes Type D tripping characteristics suitable for motors and inductive loads.
It is equipped with screw-type terminals.
This model is designed for DIN Rail mounting.
The mount hole size is 4.5 mm.
It complies with IEC, EN, EAC, CE, CCC, and RoHS standards.
The country of origin is India.
