Relpol PCB Power Relay 3V DC Coil 15A Switching Current SPDT RM50-3011-85-1003
Specifications
| Country of Origin | Poland |
|---|---|
| Brand | Relpol |
| Height | 15.5mm |
| Length | 19mm |
| Model | RM50-3011-85-1003 |
| Width | 15.4mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | RM50 |
| Maximum Operating Temperature | 55°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -30°C |
| Switching Current | 15A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 25Ω |
| Coil Voltage | 3V dc |
| Switching DC Voltage | 48V dc |
| Switching AC Voltage | 48V ac |
| Coil Power | 360mW |
Key Features
- The coil voltage is 3V DC, suitable for low-voltage applications.
- Contact configuration is Single Pole Double Throw (SPDT) for versatile switching.
- Supports high switching current up to 15A for robust performance.
- Compact dimensions of 19mm length, 15.4mm width, and 15.5mm height.
- High switching power of 3kVA for reliable electrical load handling.
- Operating temperature range from -30°C to 55°C for durability in harsh environments.
- Contact material is silver alloy ensuring low contact resistance of 100mΩ.
- PCB pin terminal type facilitates easy PCB mounting integration.
Product Description
Relpol RM50-3011-85-1003 PCB Power Relay is engineered for general-purpose applications requiring reliable switching on printed circuit boards. It features a 3V DC coil and can switch currents up to 15A using an SPDT (Single Pole Double Throw) contact configuration. This relay belongs to the RM50 series, known for compact size and high performance.
The relay is designed for PCB mounting with convenient PCB pin terminals, making it ideal for use in automotive, machinery, and electronic equipment. Its compact form factor (19mm length, 15.4mm width, 15.5mm height) allows integration into densely packed assemblies.
Operating reliably across temperatures from -30°C to 55°C, this relay is well suited for industrial environments with vibration and shock resistance. The contact material uses silver alloy delivering low contact resistance at 100mΩ, enhancing electrical efficiency and longevity.
With a switching power rating of 3kVA and switching voltages up to 48V AC or DC, it supports substantial electrical loads. The coil resistance is 25Ω with a power consumption of 360mW, ensuring low energy use.
3V DC coil voltage for low voltage circuits. 15A switching current capacity for heavy-duty switching. Compact PCB mounting form factor with pin terminals. Wide operating temperature range from -30°C to 55°C. Silver alloy contacts for durability and low resistance.
Switching power rating of 3kVA suitable for various applications. Compliant with RoHS environmental standards.
This power relay is applicable in industrial, laboratory, automotive, manufacturing, and electronic sectors where robust and compact PCB mounted relays are required. It enables efficient circuit control and switching in diverse environments.
Explore more Power Relays and related components at EnvMart to find suitable solutions for your electrical and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this relay is 3V DC, making it suitable for low-voltage applications.
It can handle a maximum switching current of 15A, allowing for robust performance in various applications.
This relay features a Single Pole Double Throw (SPDT) contact configuration, providing versatile switching options.
The dimensions of this relay are 19mm in length, 15.4mm in width, and 15.5mm in height, allowing for compact integration.
The operating temperature range for this relay is from -30°C to 55°C, making it suitable for harsh environments.
The contact material is silver alloy, which ensures low contact resistance of 100mΩ, enhancing electrical efficiency.
The switching power rating of this relay is 3kVA, suitable for handling substantial electrical loads.
This relay uses PCB pin terminals, facilitating easy PCB mounting integration.
It supports switching voltages up to 48V AC or DC, allowing for versatile application across different circuits.
The coil resistance is 25Ω, with a power consumption of 360mW, ensuring low energy use.
Yes, this relay is compliant with RoHS environmental standards, ensuring it meets specific environmental regulations.
This relay is applicable in industrial, laboratory, automotive, manufacturing, and electronic sectors for reliable circuit control.
