NSK-RHP Bearing Unit Set Screw Locking Cast Iron Housing 30 mm ID ST30 R

NSK-RHP ST30 Bearing Unit is a high-quality bearing take-up unit featuring a 30 mm inside diameter and set screw locking type. The housing is made from cast iron conforming to BS1452 standards, offering robust durability and long service life.

This take-up unit is designed to adjust slackness in conveyor belts by inserting a nut into the slot and tightening a bolt through the casting to ensure optimal belt tension.

The spherical bearing insert allows for initial misalignment, enhancing operational reliability. Sealed with nitrile fabric seals, it provides protection against dust and moisture, extending bearing life.

With a static load rating of 11.3 kN and a limiting speed of 5300 rpm, this bearing unit is suitable for demanding industrial environments such as conveyor systems, agricultural equipment, and food processing applications.

The product includes grease nipples to facilitate proper lubrication and maintenance during operation. The bearing unit has a cast iron housing made to BS1452 standards. Set screw locking secures the bearing insert firmly.

Spherical bearing insert allows accommodation of initial misalignment. Equipped with nitrile/fabric seals for protection against contaminants. Designed for static load rating of 11.3 kN and limiting speed of 5300 rpm. Supplied with grease nipples for convenient maintenance.

Dimensions include length 115.5 mm, width 101.5 mm, and depth 36.5 mm. Typically used in conveyor systems, food processing, and agricultural equipment applications. EnvMart provides a comprehensive range of mechanical components including Bearing Units suited for industrial, manufacturing, conveyor, and agricultural sectors.
