MK Electric 13A 1 Gang Switched Fused Spur High Grade Thermoset Surface/Flush Mount K370 WHI

MK Electric K370 WHI 1 Gang Switched Fused Spur is a high quality electrical component designed for safe connection of fixed appliances such as refrigerators, water heaters, and central heating boilers. This unit is constructed from high grade thermoset material featuring antimicrobial properties, making it suitable for commercial, industrial, and residential electrical installations where hygiene is key.

The product is rated for 13A current and 250V AC operation. It supports both surface and flush mounting installation methods with compact dimensions of 86 mm square faceplate and a depth of 12.5 mm (faceplate depth 15 mm). The design is part of the Logic Plus range, known for reliability and installer-friendly features.

This Fused Spur includes a switch with neon indicators visible at 175 degrees horizontally and vertically, enhancing operational awareness. The fuse carrier is lockable in the open position, providing additional safety during fuse replacement. The unit has a screwless design with push-fit cord grips for quick and secure cable connections. Angled, top-mounted terminal screws simplify the wiring process, and all terminal screws are captive and backed out for safe handling. The unit has a lock feature on the fuse carrier and a neutral make first, break last feature to ensure electrical safety.

Installation requires a flush mounting back box with a minimum depth of 35 mm. The product conforms to numerous stringent standards including BS EN 61558-2-5:1998, BS 5733:2010, BS 1363 Pt 2:1995, BS EN 60669-2-1, and many others, providing assurance of quality, performance, and safety compliance.

This 1 gang unit is suitable for a wide range of industrial, commercial, and residential applications including HVAC systems, water treatment, manufacturing plants, and domestic electrical setups. Its robust design and antimicrobial thermoset material make it especially ideal for environments demanding enhanced hygiene and safety.

The MK Electric Logic Plus range offers modern aesthetics with high gloss white finish and integrates numerous practical features to reduce installation time and boost durability. The unit features a high grade thermoset material with antimicrobial properties for enhanced hygiene.

It supports a current rating of 13A with a nominal voltage of 250V AC suitable for fixed appliances connection. Mount type is surface or flush installation with precise dimensions of 86mm width and height. The switch is screwless with a secure earth terminal and a lockable fuse carrier for safety.

Includes neon indicators for switch position visibility at 175 degrees in both planes. Designed for ease of installation with push-fit cord grips and angled terminal screws. Flush mounting back box requires a minimum depth of 35mm for mounting.

Complies with numerous international standards including BS EN 61558-2-5 and BS 1363 Pt 2:1995 among others. Explore more from the MK Electric Logic Plus range at EnvMart for reliable and safe electrical switching devices.
