Texas Instruments Operational Amplifier 10 MHz 15V SOIC 8-Pin NE5532AD
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | NE5532AD |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | NE55 |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 15V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 10MHz |
| Input Bias Current | 1000 nA |
| Vos - Input Offset Voltage | 5 mV |
| Slew Rate | 9V/μs |
| Input Offset Current | 200 nA |
Key Features
- This dual operational amplifier provides low noise performance for audio and industrial applications.
- Operates with a supply voltage range from 5V to 15V for flexible design choices.
- Has a gain bandwidth product of 10 MHz enabling high frequency signal amplification.
- Features a slew rate of 9 V/μs ensuring fast transient response.
- Input offset voltage maximum of 5 mV minimizes drift errors.
- Compact dimensions with a 4.9 mm length, 3.91 mm width, and 1.58 mm height SOIC package.
- Suitable for surface mount technology with 8 pins and dual channels.
- Operating temperature range from 0°C to 70°C for standard environments.
Product Description
Texas Instruments NE5532AD operational amplifier is a precision dual-channel device suitable for audio, industrial, and instrumentation applications. It offers a gain bandwidth product of 10 MHz and operates at supply voltages from 5V up to the maximum 15V, housed in an 8-pin SOIC surface-mount package measuring 4.9 mm length, 3.91 mm width, and 1.58 mm height.
This device features low input offset voltage of 5 mV and low input bias and offset currents which contributes to high accuracy in signal amplification. The 9 V/μs slew rate supports fast response to input signal changes, ideal for audio and active filter circuits.
The product operates reliably within a temperature range of 0°C to 70°C, making it suitable for commercial and industrial use but not rated for automotive applications. It is designed without any specific standards or approvals but is widely recognized for its robust semiconductor performance.
The NE5532AD offers ease of integration with surface mount assembly using its standard SOIC package and 8-pin configuration. Ideal for replacing or upgrading dual op-amps in various amplifying and filtering circuits.
Low noise dual operational amplifier increases signal fidelity. Surface mount SOIC 8-pin package reduces board footprint. Slew rate of 9 V/μs for quick transient response. Wide supply voltage range from 5 to 15 volts. Stable performance over 0°C to 70°C operating temperature.
Compact dimensions suitable for dense circuit boards. Input offset and bias currents optimized for precision applications. No automotive standard compliance, for commercial and industrial use. Dual channel operation supports stereo or differential signal applications.
Ideal for audio, instrumentation, and general amplification circuits.
This amplifier is a key component in electronics and semiconductor product lines, widely utilized in laboratory instruments, audio equipment, and industrial control circuits. Explore additional Operational Amplifiers and related semiconductor components in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 10 MHz, allowing for high frequency signal amplification.
It operates with a supply voltage range from 5V to a maximum of 15V, providing flexibility for various design choices.
This operational amplifier has compact dimensions measuring 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height.
The slew rate of the NE5532AD is 9 V/μs, which ensures a fast transient response to input signal changes.
The maximum input offset voltage is 5 mV, which helps minimize drift errors in signal amplification.
This model features dual-channel operation, making it suitable for stereo or differential signal applications.
The operational amplifier operates reliably within a temperature range of 0°C to 70°C.
It is housed in a SOIC 8-pin surface mount package, which is suitable for surface mount technology.
The input bias current is 1000 nA, contributing to its high accuracy in signal amplification.
This operational amplifier is suitable for audio, instrumentation, and general amplification circuits.
The input offset current is 200 nA, which further enhances its precision in applications.
The NE5532AD is manufactured in India, as indicated by its country of origin.
