SICK Plastic Glass Fibre Optic Sensor PNP Output IP50 24V dc WLL180T-M432

SICK WLL180T-M432 Plastic Glass Fibre Optic Sensor with PNP output provides a reliable and fast detection solution for industrial automation applications. Operating at 24V dc and featuring an IP50 rated plastic housing, this sensor is designed for demanding environments requiring accurate object detection and level measurement.

The sensor achieves a response time as fast as 16 microseconds, enabling rapid process monitoring. With a sensing range of up to 20 meters in through-beam configuration and 1400 mm in proximity mode, it can be used effectively in a variety of industrial and manufacturing settings.

Equipped with an LED light source and a cable terminal, it supports a switching frequency of 31.2 kHz. The device includes two 4-digit displays that facilitate easy setup, diagnostics, and status indication through an intuitive menu system.

This sensor includes advanced features such as adjustable hysteresis and programmable time delays, allowing fine adjustment for detection of small or transparent objects. It supports bus communication with built-in anti-interference logic that prevents cross-talk between sensors in cluster installations.

Typical applications include printed circuit board detection, level measurement in containers, log detection and classification, gripper and injection molding tool monitoring, as well as presence and end-position checking in automated loading and insertion processes.

The WLL180T sensor family ensures robust operation even in conditions with dust, mist, or spray, and is suitable for use in vacuum environments and solar cell production protrusion monitoring.

Selectable response time up to 16 microseconds. Sensing range up to 20 meters (through-beam) and 1400 mm (proximity). Bus-compatible with anti-interference for reliable network operation. Two 4-digit digital displays for easy programming and monitoring.

Adjustable hysteresis and programmable time delays for application flexibility. Rotatable display screen for convenient viewing under difficult installation conditions. Durable plastic housing with IP50 ingress protection.

Operating temperature range from -25°C to 55°C. Compliance with UL and CE standards. Explore the full range of SICK sensors and automation components on EnvMart for reliable industrial solutions.
