STMicroelectronics Dual 20 MHz Bandwidth Surface Mount Operational Amplifier, 8-Pin DFN-8 TSV772IQ2T
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Model | TSV772IQ2T |
| Mount Type | Surface |
| Series | TSV772 |
| Maximum Operating Temperature | 125°C |
| Package Type | DFN-8 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | ANSI/ESD S20.20:2021, RoHS |
| Pin Count | 8 |
| Minimum Supply Voltage | 2V |
| GBP - Gain Bandwidth Product | 20MHz |
| Input Bias Current | 75 pA |
| Input Offset Current | 20 pA |
| Standards/ApprovalsANSI/ESD S20.20 | 2021, RoHS |
| Low input bias current | 2 pA typ |
Key Features
- The amplifier features a rail-to-rail input stage with low input offset voltage of 700 μV.
- It operates from a minimum supply voltage of 2V up to 5.5V single supply.
- Low input bias current of 75 pA and low noise of 7 nV/√Hz enhance signal accuracy.
- The device has a slew rate of 13 V/μs for fast signal response.
- It is unity-gain stable and designed for high bandwidth applications.
- Operating temperature range extends from -40°C to 125°C, suitable for industrial use.
- Ideal for low-side current sensing and photodiode amplifier applications.
- The compact DFN-8 package enables efficient PCB space utilization.
Product Description
STMicroelectronics TSV772IQ2T is a high bandwidth, low offset dual operational amplifier designed for industrial and automotive signal conditioning applications. Featuring a gain bandwidth product of 20 MHz and unity-gain stability, this amplifier supports precise amplification of small signals with excellent accuracy. The rail-to-rail input stage and low input offset voltage (700 μV) allow for effective measurement in low voltage environments.
This surface mount device comes in an 8-pin DFN-8 package, supporting a supply voltage range from 2.0 V to 5.5 V, making it adaptable for a variety of power management systems. Its low input bias current (typical 75 pA) and low noise density (7 nV/√Hz) ensure minimal signal distortion, which is critical in precision analog circuitry.
The TSV772IQ2T operates reliably over a broad temperature range from -40 °C to +125 °C and complies with ANSI/ESD S20.20:2021 and RoHS regulations. The device features a slew rate of 13 V/μs and supports output capacitance up to 47 pF, making it well-suited for use as an ADC input buffer or low-side current sensor in automotive and power system applications.
Typical applications include high bandwidth current sensing, photodiode amplifiers, active filters, and signal conditioning solutions in solar-powered systems or other industrial scenarios requiring accurate low-voltage operation.
The amplifier offers excellent gain bandwidth product of 20 MHz for fast, stable operation. Low offset voltage and input bias current provide high precision for sensitive measurements. Industrial temperature range ensures suitability for harsh environments.
Compact DFN-8 surface mount package facilitates space-saving PCB layouts. Compliance with industry standards assures quality and reliability.
For detailed design and performance information, consult the technical datasheets and design resources provided by STMicroelectronics. Explore our wide range of Operational Amplifiers in the EnvMart electronics components category for your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the TSV772IQ2T is 20 MHz, enabling fast and stable operation in high bandwidth applications.
It operates with a supply voltage range from 2.0 V to 5.5 V, making it suitable for various power management systems.
The input offset voltage of the TSV772IQ2T is 700 μV, allowing for effective measurement in low voltage environments.
This model operates reliably over a temperature range from -40°C to +125°C, suitable for industrial applications.
The TSV772IQ2T is a dual operational amplifier, featuring two channels.
The slew rate of the TSV772IQ2T is 13 V/μs, which supports fast signal response.
It comes in an 8-pin DFN-8 surface mount package, facilitating efficient PCB space utilization.
The input bias current is typically 75 pA, which helps ensure minimal signal distortion.
This operational amplifier complies with ANSI/ESD S20.20:2021 and RoHS regulations, ensuring quality and reliability.
It is ideal for applications such as low-side current sensing, photodiode amplifiers, and signal conditioning in industrial settings.
The noise density of the TSV772IQ2T is 7 nV/√Hz, which enhances signal accuracy in precision analog circuitry.
The input offset current for this model is 20 pA, contributing to its high precision for sensitive measurements.
