| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Model | SN74LVC1G04DBVR |
| Mount Type | Surface |
| Series | SN74LVC1G04D |
| Input Type | CMOS |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | 74LVC |
| Logic Function | Inverter |
| Minimum Supply Voltage | 1.65V |
| Maximum High Level Output Current | -4mA |
| Maximum Propagation Delay Time @ CL | 7.5ns |
| Maximum Low Level Output Current | 32mA |
Texas Instruments SN74LVC1G04DBVR is a high-performance inverter logic integrated circuit housed in a compact 5-pin SOT-23 surface mount package. It features a single inverter element per chip optimized for CMOS input signals and designed to operate over a supply voltage range of 1.65 to 5.5 volts.
This device is engineered for fast signal switching with a maximum propagation delay time of 7.5 nanoseconds at standard load conditions, making it suitable for various industrial and commercial electronic applications requiring reliable logic inversion functions.
Operating temperature range from -40 degrees Celsius up to 125 degrees Celsius ensures robust performance in harsh environments. Compliance with RoHS confirms adherence to environmental safety standards.
The logic family 74LVC provides low power consumption and compatibility with modern CMOS logic designs, enabling integration into complex semiconductor circuits. The device offers maximum low level output current of 32 milliamps and a high level output current capability of -4 milliamps.
Ideal for electronics manufacturing, embedded system development, and semiconductor design, this part is well-suited for applications in signal processing, industrial automation, and power supply control modules.
The device incorporates a single inverter logic element per chip delivering high efficiency. It operates over a supply voltage range from 1.65V to 5.5V for flexible integration. The maximum propagation delay time at CL load is 7.5 nanoseconds ensuring fast switching.
Designed for surface mount applications with a compact SOT-23 package type. Operates reliably within a wide temperature range of -40 to 125 degrees Celsius. Complies with RoHS standards guaranteeing environmentally safe production.
Logic family 74LVC delivers CMOS compatibility and low power dissipation. Pin count of 5 pins enables straightforward PCB design and mounting. This product is new and meets quality standards without automotive qualification.
