Hongfa Europe GMBH PCB Power Relay 5V DC Coil 10A Switching Current DPDT HF140FF/005-2ZTF

Hongfa Europe GMBH HF140FF/005-2ZTF PCB Power Relay is a non-latching electromagnetic relay designed for reliable switching applications. It is actuated by a 5V DC coil with a switching current capacity of 10A in a DPDT (double pole double throw) contact configuration. The relay is suitable for mounting on printed circuit boards, featuring PCB pin terminals for straightforward installation.

This power relay is constructed with silver alloy contacts that ensure low contact resistance and high conductivity, making it effective for switching both DC and AC loads. Its compact dimensions of 29mm length, 13mm width, and 26.3mm height allow for space-efficient electronics design.

Engineered to operate within a temperature range from -40°C to 85°C, the relay performs reliably in harsh industrial and automotive environments. It features an isolation voltage of 5 kVAC between coil and contacts to protect sensitive circuitry. The coil resistance is 47Ω and coil power consumption is 530mW, optimizing energy efficiency.

This relay complies with RoHS standards, ensuring it is an environmentally friendly choice for OEMs focused on sustainability. Its durability rating supports up to 10 million operational cycles, underscoring its suitability for demanding and continuous industrial use.

The HF140FF/005-2ZTF relay is ideal for applications such as automotive control systems, home automation, industrial machinery control, and other electrical switching tasks where compact size, high switching power, and reliable operation are essential.

This power relay features high power switching capability suitable for DC and AC applications. Operates with a coil voltage of 5V DC, ensuring low power consumption. Designed for PCB mount with PCB pin terminals for easy integration.

Durable contact material of silver alloy delivers low contact resistance for reliable performance. Wide operating temperature range from -40°C to 85°C, suitable for diverse environments. Isolation voltage of 5 kVAC between coil and contacts for enhanced safety.

Compact size with dimensions approximately 29mm length, 13mm width, and 26.3mm height. This relay offers durability with an operational life of up to 10 million cycles. Compliance with RoHS standards ensures environmental friendliness.

Ideal for automotive, control devices, and various electrical automation applications. Explore more Power Relays and related components for industrial electronics at EnvMart.
