SICK Retroreflective Photoelectric Sensor, Block Style, 6.5 m Detection Range, PNP Output, IP69K, IP67, HL18-P4A3BE
Specifications
| Country of Origin | United States |
|---|---|
| Brand | SICK |
| Response time | 500μs |
| Light Source | LED |
| Detection range | 6.5 m |
| Model | HL18-P4A3BE |
| IP Rating | IP69K, IP67 |
| Mount Type | Threaded |
| Housing Material | Plastic |
| Output type | PNP |
| Series | SureSense |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -40°C |
| Maximum Current | 100mA |
| DetectIon Type | Retroreflective |
| Terminal type | 4-Pin Connector |
| Maximum dc Voltage | 30V dc |
| Standards/Approvals | UL File No. E189383, EMC EN 60947-5-2 |
| Sensor Style | Block |
Key Features
- The sensor features a 4-pin connector and LED light source for precise detection.
- Operating voltage max 30V DC and max current 100mA ensure efficient performance.
- Rugged plastic VISTAL housing provides excellent durability and impact resistance.
- Threaded mount type allows flexible and secure installation.
- Suitable for industrial automation, presence monitoring, and harsh environment applications.
- Wide operating temperature range from -40°C to 70°C.
- Response time of 500 microseconds supports fast sensing tasks.
- Compliant with UL File No. E189383 and EMC EN 60947-5-2 standards.
Product Description
SICK HL18-P4A3BE Retroreflective Photoelectric Sensor offers superior detection capabilities with a block sensor style, 6.5 m detection range and PNP output type. Encased in a rugged VISTAL plastic housing rated to IP69K and IP67, this sensor is built for demanding industrial environments requiring reliable automation control.
This sensor integrates an LED light source and a 4-pin connector terminal type supporting maximum 30V DC voltage and 100mA current rating. Its robust VISTAL housing - nine times stronger than standard ABS - enhances resistance to wear and damage. Threaded mounting options provide secure installation flexibility.
Capable of operating within a temperature range of -40°C to 70°C and featuring a rapid 500μs response time, it is suitable for presence monitoring, conveyor systems, and object detection applications including pallets and various materials such as black, shiny, transparent, and differently colored objects. The intuitive signal strength light bar enables straightforward installation and troubleshooting.
Certified under UL File No. E189383 and EMC EN 60947-5-2, this sensor assures compliance with industry standards. It forms part of the SureSense series known for versatile sensing options and advanced AutoAdapt technology for reliable transparent object detection.
This product is manufactured in the United States and designed for demanding industrial, automation, manufacturing, and material handling processes. The sensor features a 4-pin connector and LED light source for precise detection.
Operating voltage max 30V DC and max current 100mA ensure efficient performance. Rugged plastic VISTAL housing provides excellent durability and impact resistance. Threaded mount type allows flexible and secure installation.
Suitable for industrial automation, presence monitoring, and harsh environment applications. Wide operating temperature range from -40°C to 70°C. Response time of 500 microseconds supports fast sensing tasks. Compliant with UL File No. E189383 and EMC EN 60947-5-2 standards.
Designed for detection of various objects including transparent and shiny surfaces. Explore EnvMart's extensive catalog for more advanced sensors and automation control gear to enhance your industrial processes.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The detection range of this sensor is 6.5 meters.
It features a PNP output type.
This model has an IP rating of IP69K and IP67, making it suitable for harsh environments.
The maximum operating temperature is 70°C.
The response time of this sensor is 500 microseconds.
The sensor is encased in a rugged plastic VISTAL housing.
It features a threaded mount type for flexible and secure installation.
The minimum operating temperature is -40°C.
It operates at a maximum voltage of 30V DC.
The sensor is compliant with UL File No. E189383 and EMC EN 60947-5-2 standards.
It uses an LED light source for detection.
This sensor is suitable for industrial automation, presence monitoring, and object detection applications.
