TE Connectivity SSRMP Series Solid State Relay Panel Mount 10A Load 480V Load SSRMP-480D10
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | TE Connectivity |
| Height | 23.5mm |
| Length | 35.5mm |
| Model | SSRMP-480D10 |
| Width | 21.8mm |
| Mount Type | Panel |
| Output type | Current/Voltage |
| Series | SSRMP |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -30°C |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 10A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 480V |
| Minimum Load Voltage | 48V |
Key Features
- Rated maximum load current of 10 amps for diverse industrial applications.
- Panel mount design enables convenient and secure installation in control panels.
- Supports load voltages ranging from 48 volts minimum up to 480 volts maximum.
- Employs SPST contact configuration with zero cross switching function for reduced electrical noise.
- Operates reliably within a temperature range of -30°C to 80°C.
- Compact dimensions measuring approximately 35.5 mm length, 23.5 mm height, and 21.8 mm width.
- Quick connect terminals facilitate fast and safe wiring connections.
- Certified RoHS compliant ensuring environmental safety and regulatory adherence.
Product Description
TE Connectivity SSRMP-480D10 is a panel mount solid state relay designed for industrial automation, heating, lighting, and machinery applications. It offers silent operation, fast switching, and long electrical life, making it suitable for various electrical control scenarios requiring efficient power management at currents up to 10A and voltages up to 480V.
The SSRMP series solid state relay supports load voltages from 48V to 480V and features a Single Pole Single Throw (SPST) contact configuration with zero cross switching technology. This reduces switching noise and increases reliability, especially in sensitive automation environments.
Its compact size (35.5 mm length, 23.5 mm height, 21.8 mm width) and quick connect terminals simplify panel mounting and wiring, making it an excellent choice for industrial and commercial control systems operating within a temperature range of -30°C to 80°C.
The relay is RoHS compliant and manufactured in Germany, ensuring adherence to environmental standards and high product quality. Typical use cases include industrial machinery control, heating element switching, lighting systems, and various automation applications requiring silent and efficient relay switching.
Rated maximum load current of 10 amps for diverse industrial applications. Panel mount design enables convenient and secure installation in control panels. Supports load voltages ranging from 48 volts minimum up to 480 volts maximum.
Employs SPST contact configuration with zero cross switching function for reduced electrical noise. Operates reliably within a temperature range of -30°C to 80°C. Compact dimensions measuring approximately 35.5 mm length, 23.5 mm height, and 21.8 mm width.
Quick connect terminals facilitate fast and safe wiring connections. Certified RoHS compliant ensuring environmental safety and regulatory adherence. Manufactured in Germany with high quality standards for durability and performance.
Explore the range of Solid State Relays at EnvMart for industrial and automation solutions with trusted brands like TE Connectivity.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SSRMP-480D10 has a maximum load current rating of 10 amps, suitable for various industrial applications.
This model supports load voltages ranging from a minimum of 48 volts up to a maximum of 480 volts.
It employs a Single Pole Single Throw (SPST) contact configuration, which is designed to minimize electrical noise through zero cross switching.
The dimensions of this relay are approximately 35.5 mm in length, 23.5 mm in height, and 21.8 mm in width.
It operates reliably within a temperature range of -30°C to 80°C.
This model features a panel mount design, allowing for convenient and secure installation in control panels.
The quick connect terminals facilitate fast and safe wiring connections, simplifying the installation process.
Yes, it is certified RoHS compliant, ensuring adherence to environmental safety and regulatory standards.
This relay is suitable for industrial automation, heating, lighting, and machinery applications requiring efficient power management.
This model is manufactured in Germany, ensuring high quality standards.
The relay features a zero cross switching function, which helps reduce electrical noise during operation.
It provides both current and voltage output, suitable for various control scenarios.
