STMicroelectronics 150 V 1 A Surface Mount Schottky Diode DO-214AC STPS1150A
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 2.71mm |
| Brand | STMicroelectronics |
| Height | 2.03mm |
| Length | 4.6mm |
| Model | STPS1150A |
| Width | 2.95mm |
| Mount Type | Surface |
| Series | STPS1150 |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 150V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 75A |
| Maximum Forward Voltage Vf | 0.62V |
Key Features
- Compact DO-214AC package designed for surface mounting applications.
- Maximum forward voltage drop of 0.62 V for high efficiency.
- Operates reliably from -65°C up to 175°C maximum temperature.
- Supports peak non-repetitive forward surge current up to 75 A.
- Single diode configuration with 2 pins for easy integration.
- Low peak reverse current of 1 μA enhances device performance.
- Small physical dimensions with length 4.6 mm, width 2.95 mm, height 2.03 mm, diameter 2.71 mm.
- No automotive standard certification, suitable for general industrial and commercial use.
Product Description
STMicroelectronics STPS1150A is a high-performance Schottky barrier diode designed for surface mount technology in electronic circuits. It supports a maximum continuous forward current of 1 A and can withstand peak reverse repetitive voltages up to 150 V. The diode features a low forward voltage drop of 0.62 V, contributing to efficient power rectification and reduced heat generation in electronic devices.
This 2-pin diode in a DO-214AC package is suitable for compact applications where space-saving is essential. It operates reliably over a wide temperature range from -65°C to 175°C, making it suitable for diverse environments including industrial and commercial electronics, power management circuits, and consumer electronics.
Its capability to endure peak non-repetitive forward surge currents up to 75 A ensures durability during transient conditions. Additionally, the low peak reverse current of 1 µA reduces power loss and enhances the overall performance in switching and rectification applications.
Compact DO-214AC package designed for surface mounting applications. Maximum forward voltage drop of 0.62 V for high efficiency. Operates reliably from -65°C up to 175°C maximum temperature. Supports peak non-repetitive forward surge current up to 75 A.
Single diode configuration with 2 pins for easy integration. Low peak reverse current of 1 μA enhances device performance. Small physical dimensions with length 4.6 mm, width 2.95 mm, height 2.03 mm and diameter 2.71 mm.
No automotive standard certification, suitable for general industrial and commercial use.
This Schottky diode is commonly used in power supplies, voltage clamping, reverse current protection, and fast switching circuits in industrial, laboratory, and electronic manufacturing environments. Its robust design supports a wide range of electronic applications demanding high efficiency and reliability.
Explore more Schottky Diodes and rectifiers to suit your custom electronic project needs on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the STMicroelectronics STPS1150A is 1 A.
This model can withstand a peak reverse repetitive voltage of up to 150 V.
The maximum forward voltage drop for this diode is 0.62 V.
It operates reliably over a temperature range from -65°C to 175°C.
The diode is packaged in a DO-214AC format suitable for surface mounting applications.
This diode features a single configuration with 2 pins for easy integration.
It supports a peak non-repetitive forward surge current of up to 75 A.
The dimensions are as follows: length 4.6 mm, width 2.95 mm, height 2.03 mm, and diameter 2.71 mm.
The peak reverse current is rated at 1 μA, which enhances device performance.
This Schottky diode is commonly used in power supplies, voltage clamping, reverse current protection, and fast switching circuits.
The STMicroelectronics STPS1150A is manufactured in India.
This model is a Schottky rectifier, which is known for its low forward voltage drop and fast switching capabilities.
