Renesas Electronics Dual Operational Amplifier 4.5 MHz Gain Bandwidth, 8-Pin PDIP Package CA3240EZ
Specifications
| Country of Origin | India |
|---|---|
| Brand | Renesas Electronics |
| Height | 4.95mm |
| Length | 10.16mm |
| Model | CA3240EZ |
| Width | 7.11mm |
| Mount Type | Through Hole |
| Series | CA3240 |
| Output Current | 20mA |
| Maximum Operating Temperature | 85°C |
| Package Type | PDIP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 4.5MHz |
| Input Bias Current | 50 pA |
| Vos - Input Offset Voltage | 15 mV |
| Slew Rate | 7V/μs |
| Input Offset Current | 32 pA |
| Intersil CA3240EZ, Dual Op Amp, 4.5MHz, 5 → 28 V, 8-Pin PDIPBrand | Intersil |
Key Features
- Contains two channels for dual signal amplification.
- Operating voltage range from 5 V minimum to 36 V maximum supply.
- Low input bias current of 50 pA for high precision applications.
- Slew rate of 7 V/μs enabling fast signal response.
- Wide operating temperature range from -40°C to 85°C ensures reliable operation.
- Compact PDIP package with dimensions 10.16mm length, 7.11mm width, and 4.95mm height.
- Input offset voltage typically 15 mV for accurate amplification.
- Output current up to 20 mA suited for various load conditions.
Product Description
Renesas Electronics CA3240EZ is a dual operational amplifier featuring a 4.5 MHz gain bandwidth and housed in an 8-pin PDIP through-hole package. It is designed for precision amplification tasks in electronics and semiconductor industries. The device supports a minimum supply voltage of 5 V and can handle up to 36 V maximum, making it versatile for a wide range of circuits.
Featuring MOSFET input stages, the amplifier provides high input impedance and low input current, critical for sensitive signal processing. An input bias current of 50 pA and low input offset current of 32 pA improve signal integrity. The slew rate of 7 V/μs allows for quick voltage changes, enabling high-frequency signal amplification.
The amplifier is rated for operation from -40°C to 85°C, suitable for industrial environments and electronics manufacturing. Its compact PDIP form factor measures 10.16mm in length, 7.11mm in width, and 4.95mm in height, fitting standard PCB layouts.
The output current capability of 20 mA allows driving of moderate loads directly. Input offset voltage is controlled at approximately 15 mV to maintain accuracy. CA3240EZ is RoHS compliant, aligning with modern environmental standards.
Dual operational amplifier with two channels. Gain bandwidth product of 4.5 MHz for high-speed applications. Wide supply voltage range supporting 5 V to 36 V. Low input bias current and offset current for precision. Standard 8-pin PDIP package suitable for through-hole mounting.
Operating temperature range from -40°C to 85°C. Internally compensated with MOSFET input and bipolar output. Output current capability of up to 20 mA. Compact dimensions ideal for PCB integration. RoHS compliant electronic component.
This operational amplifier is ideal for industrial, electronic component manufacturing, instrumentation, semiconductor applications, and educational laboratory projects. It offers reliable performance for dual signal amplification with fast response and high input impedance.
Explore more Operational Amplifiers and semiconductor components in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 4.5 MHz, making it suitable for high-speed applications.
This model operates within a supply voltage range of 5 V to 36 V.
The input bias current is 50 pA, which is beneficial for high precision applications.
It can provide an output current of up to 20 mA, allowing it to drive moderate loads directly.
The dimensions of the PDIP package are 10.16 mm in length, 7.11 mm in width, and 4.95 mm in height.
The slew rate is 7 V/μs, enabling fast signal response for quick voltage changes.
The input offset voltage is typically 15 mV, which helps maintain accuracy in amplification.
It operates within a temperature range of -40°C to 85°C, suitable for various industrial environments.
This operational amplifier supports through-hole mounting, fitting standard PCB layouts.
Yes, the CA3240EZ is RoHS compliant, aligning with modern environmental standards.
This model features two channels for dual signal amplification.
The input offset current is 32 pA, which contributes to improved signal integrity.
