DiodesZetex Non-Inverting Push Pull Buffer Logic IC, 6-Pin SOT-363, 1.65-5.5 V, 40 μA Supply Current, 74LVC2G34DW-7

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex Non-Inverting Push Pull Buffer Logic IC, 6-Pin SOT-363, 1.65-5.5 V, 40 μA Supply Current, 74LVC2G34DW-7

Name: DiodesZetex Non-Inverting Push Pull Buffer Logic IC, 6-Pin SOT-363, 1.65-5.5 V, 40 μA Supply Current, 74LVC2G34DW-7
Brand: DiodesZetex
SKU: 275665
Price: 0.12 USD
Availability: InStock



Category Buffers Brand DiodesZetex Condition New

Specifications

Country of Origin	Taiwan
Brand	DiodesZetex
Height	1mm
Length	2.2mm
Model	74LVC2G34DW-7
Mount Type	Surface
Compatibility	Input LVTTL/TTL, Output LVCMOS
Output type	Push Pull
Series	74LVC2G34
Input Type	Voltage
Maximum Operating Temperature	125°C
Package Type	SOT-363
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
Operating Voltage	1.65 to 5.5 V
Standards/Approvals	RoHS
Pin Count	6
Maximum Supply Voltage	5.5V
Logic Family	74LVC
Logic Function	Driver, Buffer
Minimum Supply Voltage	1.65V
Maximum High Level Output Current	-32mA
Supply Current	40μA
Maximum Low Level Output Current	32mA

Key Features

Offers non-inverting push pull output type for efficient signal buffering.
Compatible with input LVTTL/TTL and output LVCMOS logic levels.
Features a low supply current of 40 microamps for power-efficient applications.
Operates reliably across a temperature range of -40°C to 125°C.
Compact footprint with dimensions of 2.2mm length and 1mm height for surface mounting.
Supports maximum supply voltage of 5.5 volts ensuring broad compatibility.
Pin count is 6, provided in a surface mount SOT-363 package.
Designed for applications requiring driver and buffer logic functionalities.

Product Description

DiodesZetex 74LVC2G34DW-7 Non-Inverting Push Pull Buffer is a specialized Logic IC designed for buffering and driving applications within electronic circuits. Operating within a voltage range of 1.65 to 5.5 V and featuring a 6-pin SOT-363 surface mount package, this device ensures efficient signal integrity and low power consumption with a supply current of only 40 μA.

This logic buffer adopts low-voltage CMOS technology compatible with LVTTL/TTL input and LVCMOS output logic levels, offering robust operation from industrial temperature ranges of -40°C up to 125°C. Its non-inverting push pull output supports straightforward signal driving requirements in a compact footprint measuring 2.2mm in length and 1mm in height, making it ideal for dense PCB layouts.

With a maximum high-level output current rating of -32mA and maximum low-level output current of 32mA, the 74LVC2G34DW-7 caters to versatile signal buffering needs, suitable for industrial, laboratory, and embedded electronic systems requiring reliable logic buffering components.

Non-inverting push pull output type ensuring clear signal drive. Low supply current of 40 μA for energy-efficient operation. Wide operating temperature range from -40°C to 125°C for harsh environments. 6-pin SOT-363 surface mount package for compact PCB integration.

Compatible with voltage levels from 1.65 to 5.5 V supporting diverse systems. Conforms to RoHS environmental compliance standards.

This buffer belongs to the 74LVC2G34 family from Diodes Inc., focusing on low-voltage CMOS logic and optimized for modern electronics. It is suitable for use in industrial control systems, electronic instrumentation, communication devices, and other embedded electronics applications requiring stable signal buffering and driving capabilities.

Explore a full range of semiconductor Buffers and logic ICs available for advanced electronic design and manufacturing solutions.
