HY Electronic Corp 60 V 1 A Surface Mount Schottky Barrier Rectifier Diode DO-214AC SS16

Free Delivery in India | Lowest Global Shipping Charges

HY Electronic Corp 60 V 1 A Surface Mount Schottky Barrier Rectifier Diode DO-214AC SS16

Name: HY Electronic Corp 60 V 1 A Surface Mount Schottky Barrier Rectifier Diode DO-214AC SS16
Brand: HY Electronic Corp
SKU: 275060
Price: 0.05 USD
Availability: InStock



Category Schottky Diode Brand HY Electronic Corp Condition New

Specifications

Country of Origin	China
Brand	HY Electronic Corp
Height	2.2mm
Length	4.75mm
Model	SS16
Width	2.95mm
Mount Type	Surface
Series	FBI
Maximum Operating Temperature	125°C
Package Type	DO-214AC
Minimum Operating Temperature	-65°C
Polarity	indicated by cathode band
Pin Count	2
Maximum Continuous Forward Current If	1A
Peak Reverse Repetitive Voltage Vrrm	60V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	10mA
Peak Non-Repetitive Forward Surge Current Ifsm	40A
Maximum Forward Voltage Vf	700mV
Moulded Plastic Case (Plastic	flammability classification UL 94V-0)

Key Features

Features a moulded plastic case with UL 94V-0 flammability rating for safety.
Provides low forward voltage drop of 700 mV, improving energy efficiency.
Supports peak non-repetitive forward surge current of 40 A for transient tolerance.
Operates reliably within temperature range -65°C to 125°C.
Designed with cathode band for clear polarity identification.
Compact 2.95 mm width, 4.75 mm length, and 2.2 mm height surface mount package.
Effective in applications including free-wheeling, inverters, and polarity protection circuits.
Manufactured in China ensuring consistent quality standards.

Product Description

HY Electronic Corp SS16 is a surface mount Schottky barrier rectifier diode packaged in a DO-214AC type plastic case. It is specifically designed to provide a maximum continuous forward current of 1 A and withstand a peak reverse repetitive voltage of 60 V.

The diode features a metal-semiconductor junction with guarding epitaxial construction, resulting in a low forward voltage drop of approximately 700 mV, which enhances energy efficiency during rectification.

This model supports a peak non-repetitive forward surge current of up to 40 A, allowing it to tolerate transient current spikes effectively. Its operating temperature range extends from -65°C minimum to a maximum of 125°C, ensuring reliable performance in diverse industrial and commercial environments.

The compact dimensions of the package - 2.95 mm width, 4.75 mm length, and 2.2 mm height - make it ideal for surface mounting onto printed circuit boards. The polarity is indicated by a cathode band to facilitate correct installation.

This Schottky Diode is widely used in applications such as free-wheeling diodes in motor control, inverter circuits, and polarity protection to prevent damage from reverse voltage conditions.

Manufactured in China, this component meets the standard quality requirements for semiconductor diodes. The moulded plastic case conforms to UL 94V-0 flammability classification, providing additional safety.

Features a moulded plastic case with UL 94V-0 flammability rating for safety. Provides low forward voltage drop of 700 mV, improving energy efficiency. Supports peak non-repetitive forward surge current of 40 A for transient tolerance.

Operates reliably within temperature range -65°C to 125°C. Designed with cathode band for clear polarity identification. Compact 2.95 mm width, 4.75 mm length, and 2.2 mm height surface mount package. Effective in applications including free-wheeling, inverters, and polarity protection circuits.

Manufactured in China ensuring consistent quality standards. Explore more semiconductor diodes and electronic components at EnvMart for your industrial and commercial electronic design needs.
