Celduc Solid State Relay SKL10560 Series, 50 A Load Current, 690 V Load Voltage, PCB Mount, 14 V Control SKL10560

Celduc SKL10560 Series Solid State Relay offers robust PCB mount design with a maximum load current rating of 50 A and maximum load voltage up to 690 V. This relay is engineered to provide reliable and efficient switching for heating systems, incandescent lamps, and motor loads in industrial and commercial applications.

The relay operates with a control voltage range between 4 V and 14 V, facilitating easy integration with standard control electronics. It incorporates a zero-cross switching function to minimize electrical noise and load stress during switching cycles, thereby extending the service life of connected equipment.

Built to withstand challenging conditions, the SKL10560 features an operating temperature range from -40°C to 80°C, allowing its use in diverse environments. The compact dimensions of 24.5 mm height and 43.4 mm length make it suitable for tight PCB layouts. Its thyristor output type ensures fast and efficient load switching, while the PCB pin terminal type enables straightforward mounting.

This series complies with rigorous industry standards such as pr EN61810-xxx, EN60947-4-x, UL File E69913, and EN60947-5-1, ensuring high reliability, safety, and performance. The off-state leakage current is as low as 1 mA, contributing to energy savings in electrical circuits.

Ideal for use in industrial automation, HVAC systems, manufacturing, and process control, the Celduc SKL10560 solid state relay is a dependable choice for engineers and technicians seeking advanced electronic load control solutions.

This solid state relay is designed specifically for heating installations, incandescent lamps, and motor controls. It offers high resistance to overload currents ensuring durability and stability. The relay features a zero-cross switching function to reduce electrical noise and stress on the load.

Operating temperature range extends from -40°C up to 80°C, suitable for various industrial environments. Its compact size with a height of 24.5 mm and length of 43.4 mm supports efficient PCB integration. The output type is thyristor, offering precise and reliable load control.

Terminal type is PCB pin ensuring easy and secure installation on electronic boards. Complies with standards including pr EN61810-xxx, EN60947-4-x, UL File E69913, and EN60947-5-1 for quality and safety assurance. Off state leakage current is minimal at 1 mA, enhancing energy efficiency.
