STMicroelectronics Low Power Dual Operational Amplifier, 1.1 MHz Gain Bandwidth, 8-Pin SOIC, 3V to 30V Supply LM158DT

Name: STMicroelectronics Low Power Dual Operational Amplifier, 1.1 MHz Gain Bandwidth, 8-Pin SOIC, 3V to 30V Supply LM158DT
Brand: STMicroelectronics
SKU: 274765
Price: 1.2 USD
Availability: InStock



Category Operational Amplifier Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	1.25mm
Length	5mm
Model	LM158DT
Width	4mm
Mount Type	Surface
Series	LM158
Output Current	60mA
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-55°C
Number Of Channels	2
Pin Count	8
Automotive Standard	AEC-Q100
Maximum Supply Voltage	30V
Minimum Supply Voltage	3V
GBP - Gain Bandwidth Product	1.1MHz
Input Bias Current	20 nA
Vos - Input Offset Voltage	5 mV
Slew Rate	0.6V/μs
Input Offset Current	30 nA
Wide bandwidth (unity gain)	1.1 MHz

Key Features

Wide supply voltage range from 3V to 30V supports diverse applications.
Low input bias current of 20 nA ensures precision in signal processing.
Input offset voltage of 5 mV enables accurate amplification.
Slew rate of 0.6 V/µs balances speed and stability for signal fidelity.
Maximum output current of 60 mA suitable for varying load requirements.
Temperature range from -55°C to 125°C ensures reliable operation in harsh environments.
Compact 8-pin SOIC surface mount package with dimensions 5mm x 4mm x 1.25mm height.
Compliance with automotive standard AEC-Q100 for industrial and automotive applications.

Product Description

STMicroelectronics LM158DT is a dual operational amplifier designed for low power applications with a high gain bandwidth of 1.1 MHz. Featuring two independent, internally frequency-compensated circuits, it operates from a single supply voltage ranging between 3 V and 30 V, making it versatile for industrial, automotive, and consumer electronics.

The 8-pin SOIC surface mount chip offers a compact footprint measuring 5 mm in length, 4 mm in width, and 1.25 mm in height, ideal for space-constrained PCB layouts. Its low input bias current of 20 nA and input offset voltage of 5 mV provide precise signal amplification with minimal distortion.

This operational amplifier supports wide operating temperatures from -55°C to 125°C allowing robust performance in demanding environments. It delivers an output current up to 60 mA which accommodates varying load conditions effectively.

Additional features include a slew rate of 0.6 V/µs and compliance with the automotive AEC-Q100 standard, ensuring it meets rigorous quality and reliability criteria for automotive use cases.

The dual channel design facilitates two simultaneous analog signal processing tasks within a single compact device, enhancing system integration efficiency. Wide input voltage range from 3 V to 30 V. Low input bias current and offset voltage for accurate amplification.

High gain bandwidth of 1.1 MHz suitable for general-purpose signal processing. Robust operating temperature range for industrial applications. Compact 8-pin SOIC package compatible with surface mount technology. Automotive grade compliance ensuring suitability in vehicle electronics.

Dual amplifier channels in a single IC for space-saving designs.

This operational amplifier is ideal for applications including industrial controls, automotive electronics, signal conditioning, and instrumentation where precision and reliability are critical.

Explore more Operational Amplifiers and semiconductor products at EnvMart to suit your design needs.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The gain bandwidth product of this operational amplifier is 1.1 MHz, making it suitable for general-purpose signal processing applications.

The LM158DT operates with a supply voltage range from 3V to 30V, allowing it to be used in diverse applications.

This operational amplifier can deliver a maximum output current of 60 mA, accommodating varying load requirements effectively.

The dimensions of this model are 5 mm in length, 4 mm in width, and 1.25 mm in height, making it compact for surface mount applications.

The input bias current for this operational amplifier is 20 nA, which ensures precision in signal processing.

This model has an operating temperature range from -55°C to 125°C, ensuring reliable performance in harsh environments.

The input offset voltage of this operational amplifier is 5 mV, enabling accurate amplification of signals.

The slew rate of this operational amplifier is 0.6 V/µs, balancing speed and stability for signal fidelity.

The LM158DT is housed in a compact 8-pin SOIC surface mount package, suitable for space-constrained PCB layouts.

Yes, this operational amplifier complies with the automotive standard AEC-Q100, ensuring suitability for automotive applications.

This model features two independent channels, allowing for simultaneous analog signal processing tasks.

The LM158DT is suitable for applications including industrial controls, automotive electronics, signal conditioning, and instrumentation where precision is critical.
