Crydom Solid State Relay 25 A Load, DIN Rail Mount, 600 Vrms Load, 32V dc Control PM2260D25V
Specifications
| Country of Origin | China |
|---|---|
| Brand | Crydom |
| Height | 91.9mm |
| Length | 22.5mm |
| Model | PM2260D25V |
| IP Rating | IP20 |
| Width | 116mm |
| Mount Type | DIN Rail |
| Output type | MOSFET |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SP |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Switching Function | Zero Voltage Switching |
| Maximum Load Current | 25A |
| Standards/Approvals | RoHS, CE |
| Minimum Control Voltage | 4V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 1mA |
Key Features
- Supports maximum load current of 25 amperes.
- Operates with a maximum load voltage of 600 Vrms and minimum load voltage of 48 Vrms.
- Control voltage range from 4 V dc to 32 V dc ensuring versatile input options.
- Features screw terminal type and SP contact configuration for secure connections.
- Designed for operating temperatures between -40°C and 80°C.
- Employs zero voltage switching function for noise reduction during operation.
- Encased in an IP20 rated housing for basic touch safety.
- Utilizes MOSFET output type for efficient switching performance.
Product Description
Crydom PM2260D25V Solid State Relay is a panel mount and DIN rail mounted relay designed for high-performance industrial applications requiring reliable switching of AC or DC loads with a maximum current of 25 amperes and load voltage up to 600 Vrms.
This relay supports zero voltage switching, which reduces electrical noise and stress on the load, making it ideal for sensitive electronics and controlled industrial processes.
Featuring a compact 22.5 mm wide housing, it enables high power density installation in control panels and automation systems. The screw terminal type with SP contact configuration offers robust and secure connections suitable for industrial environments.
The device operates across a wide temperature range from -40°C to 80°C and has an IP20 rating for basic protection against touch, ensuring durability and safety in typical industrial settings.
Its output type is MOSFET, providing efficient switching and longer relay life. The relay meets CE and RoHS certifications, guaranteeing compliance with European safety and environmental standards.
Supports maximum load current of 25 amperes. Operates with a maximum load voltage of 600 Vrms and minimum load voltage of 48 Vrms. Control voltage range from 4 V dc to 32 V dc ensuring versatile input options. Features screw terminal type and SP contact configuration for secure connections.
Designed for operating temperatures between -40°C and 80°C. Employs zero voltage switching function for noise reduction during operation. Encased in an IP20 rated housing for basic touch safety. Compact dimensions: height 91.9 mm, width 116 mm, length 22.5 mm.
Utilizes MOSFET output type for efficient switching performance. Manufactured to RoHS and CE standards, ensuring compliance and quality.
This solid state relay is ideal for use in industrial automation, electrical control panels, HVAC systems, manufacturing machinery, and any application requiring reliable, low-noise switching of high AC or DC loads.
Explore more Solid State Relays and automation components in the Crydom category at EnvMart for comprehensive industrial electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this solid state relay is 25 amperes.
It operates with a maximum load voltage of 600 Vrms and a minimum load voltage of 48 Vrms.
The control voltage range for this relay is from 4 V dc to 32 V dc.
This model utilizes a MOSFET output type for efficient switching performance.
It is designed to operate within a temperature range of -40°C to 80°C.
The relay has an IP20 rating, providing basic protection against touch.
This model is designed for DIN rail mounting.
The dimensions are height 91.9 mm, width 116 mm, and length 22.5 mm.
It features a screw terminal type for secure connections.
It employs a zero voltage switching function to reduce electrical noise during operation.
This model meets RoHS and CE certifications, ensuring compliance with European safety and environmental standards.
The relay features a single pole (SP) contact configuration.
