Schneider Electric Harmony Relay Series Solid State Relay, 50 A Load, Panel Mount, 660 V ac Load, 32V dc Control SSP1A450BDT
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | Schneider Electric |
| Height | 58.9mm |
| Length | 44.5mm |
| Model | SSP1A450BDT |
| IP Rating | IP20 |
| Width | 34.29mm |
| Mount Type | Panel |
| Output type | SCR |
| Series | Harmony Relay |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Switching Function | Zero Voltage Switching |
| Maximum Load Current | 50A |
| Standards/Approvals | CE, CSA, EAC, EN/IEC 62314, RoHS, UL, REACH |
| Maximum Load Voltage | 660V ac |
| Minimum Load Voltage | 48V ac |
| Minimum Control Voltage | 4V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 1mA |
Key Features
- Rated maximum load current of 50 amperes for industrial-grade performance.
- Supports load voltages between 48V AC and 660V AC with zero voltage switching.
- Equipped with a screw terminal type for secure connections.
- Features a visual input status indicator and test button for easy troubleshooting and commissioning.
- Silent operation ensured by absence of mechanical moving parts.
- Built for harsh environments with resistance to shock, vibration, and contact contamination.
- Service temperature range from -40°C to 80°C for versatile industrial usage.
- IP20 rated protection for safety against solid foreign objects.
Product Description
Schneider Electric SSP1A450BDT is a Harmony Relay Series solid state relay engineered for reliable and maintenance-free switching of AC loads up to 50 amperes. Designed for panel mounting, this single-phase relay operates at load voltages ranging from 48V to 660V AC and accepts control inputs from 4V to 32V DC, featuring zero voltage switching to minimize electrical noise and stress on the load.
This solid state relay is equipped with screw terminals that ensure stable and safe electrical connections. It includes a visual indicator of input status and a test button, facilitating quick troubleshooting and commissioning. The absence of moving contacts allows silent operation and improves longevity with an unlimited electronic lifespan.
The relay is designed to withstand harsh industrial environments, resistant to shock, vibration, and contamination, ensuring durability and reliability for applications in industrial machinery, packaging machines, HVAC systems, injection moulding, textile machines, medical equipment, and building automation.
This model features a smart diagnostic capability with an alarm output signal that alerts to unexpected conditions, helping minimize downtime and facilitating prompt maintenance intervention.
Operating temperature ranges from -40°C to 80°C with an IP20 protection rating. It fulfills key international standards and certifications such as CE, UL, CSA, EAC, RoHS, REACH, and EN/IEC 62314, guaranteeing high quality and safety compliance.
Rated for 50A maximum load current for heavy duty industrial use. Load voltage operating range from 48 to 660V AC with zero voltage switching capability. Screw terminal connections for secure installation. Visual input status indicator and test button for easy diagnostics.
Silent, maintenance-free operation due to solid state switching. Resistant to shock, vibration, and contamination ensuring reliability. Smart diagnostic alarm output minimizes downtime and facilitates quick troubleshooting.
Operating temperature range from -40°C to 80°C suitable for diverse environments. IP20 ingress protection rating. Certified to multiple international standards including CE, UL, CSA, and RoHS.
Ideal for industrial automation, machinery control, HVAC systems, packaging machines, injection moulding, medical devices, textile manufacturing, and other commercial and industrial electrical applications.
Explore more solid state relay products and automation solutions at EnvMart to enhance your electrical system's reliability and performance.
Explore more products in our Solid State Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this model is 50 amperes, designed for heavy-duty industrial applications.
This solid state relay operates at load voltages ranging from 48V AC to 660V AC.
It accepts control inputs from 4V DC to 32V DC.
This model features zero voltage switching, which minimizes electrical noise and stress on the load.
The relay has dimensions of 58.9 mm in height, 44.5 mm in length, and 34.29 mm in width.
It is equipped with screw terminals for secure electrical connections.
The operating temperature range for this model is from -40°C to 80°C.
This relay has an IP20 protection rating, providing safety against solid foreign objects.
It complies with several international standards including CE, UL, CSA, EAC, RoHS, and REACH.
Yes, it includes a smart diagnostic capability with an alarm output signal to alert unexpected conditions.
This model is suitable for applications in industrial machinery, HVAC systems, packaging machines, and medical equipment.
The contact configuration of this solid state relay is SPST (Single Pole Single Throw).
