Schneider Electric Harmony Relay Series Solid State Relay 25 A Load 300 V AC Load Panel Mount SSP1A125BD

Schneider Electric SSP1A125BD Solid State Relay is a high-performance device suitable for panel mount installation. Built to handle a maximum load current of 25 A and a maximum load voltage of 300 V AC, this relay provides robust and reliable switching for industrial applications.

This model features zero voltage switching technology which minimizes electrical noise, ensuring longer equipment life and reduced maintenance demands. The relay offers a screw terminal connection type for secure electrical contacts and ease of installation.

Compact physical dimensions (height: 58.9mm, length: 44.5mm, width: 34.29mm) allow for efficient space utilization in control panels. Rated with an IP20 protection class, it offers protection from solid foreign objects, suitable for indoor industrial settings.

Operating temperature ranges from -40°C to 80°C, making it well suited for a wide range of industrial environments including packaging machines, injection molding equipment, HVAC systems, textile machines, and various building and medical devices.

The relay output uses a Silicon Controlled Rectifier (SCR) ensuring silent and fast switching with no moving parts, thereby enhancing reliability and offering an infinite operational lifespan. The device incorporates a low capacitance of 10pF and an off state leakage current of only 1mA, contributing to efficient power management.

Compliance with major safety and environmental standards such as CE, CSA, UL, RoHS, REACH, and EN/IEC 62314 further affirms the product’s quality and suitability for industrial use.

Offers zero voltage switching technology for reduced electrical noise. Features screw terminal type ensuring secure and easy wiring. Compact dimensions with 58.9mm height, 44.5mm length, and 34.29mm width for efficient panel mounting.

Operates efficiently across a temperature range of -40°C to 80°C. Incorporates SCR output type for reliable and maintenance-free switching. Designed with IP20 protection rating suitable for industrial environments. Capacitive load handled with 10pF capacitance and minimal off-state leakage current of 1mA.

Compliance with international standards including CE, CSA, UL, RoHS, REACH, and EN/IEC 62314. Ideal for industrial machines, HVAC systems, packaging equipment, and medical devices. Explore more products in the Solid State Relays category for comprehensive automation and control solutions.
