Moflash A8BM Series Siren Surface Mount, IP66, DC 24V, Single-Tone 108 dB @ 1m A8BM-24DCR

Free Delivery in India | Lowest Global Shipping Charges

Moflash A8BM Series Siren Surface Mount, IP66, DC 24V, Single-Tone 108 dB @ 1m A8BM-24DCR

Name: Moflash A8BM Series Siren Surface Mount, IP66, DC 24V, Single-Tone 108 dB @ 1m A8BM-24DCR
Brand: Moflash
SKU: 270536
Price: 223.27 USD
Availability: InStock



Category Mounting Equipment Brand Moflash Condition New

Specifications

Country of Origin	United Kingdom
Diameter	219mm
Brand	Moflash
Model	A8BM-24DCR
IP Rating	IP66
Mount Type	Surface
Housing Material	Polyamide
Series	A8BM
Maximum Operating Temperature	+50°C
Current Type	DC
Current consumption	470mA
Minimum Operating Temperature	-25°C
Standards/Approvals	RoHS, CE
Maximum Supply Voltage	24V
Housing Colour	Red
Tone Type	Alarm
Sound Level at 1m	108dB
Maximum Sound Level	108dB
Number of Tones	1
Base Length	219mm
Base Width	93mm
Meets EN 50130-4	2011 alarm system standards
Complies with IEC 60533	1999 standards for installation on ships
Moflash A6BM Series Siren Surface, IP66, DC 230V, 1-Tone 106 dB @ 1mBrand	Moflash
Moflash A6BM Series Surface Mount Siren, 24 V ac, 106dB at 1 m, Single-ToneBrand	Moflash

Key Features

This siren operates at 24 V DC with a current consumption of 470mA.
It produces a high sound level of 108 dB at 1 meter for clear audible alert.
The housing is red polyamide with corrosion-resistant powder-coated steel gong for durability.
Surface mount design includes four M20 cable entry knockouts for flexible wiring options.
Suitable for industrial applications including fire trucks, marine environments, and automation industries.
Designed for temperature operation from -25°C to +50°C.
Low current consumption provides energy-efficient performance.

Product Description

The Moflash A8BM-24DCR is a single-tone surface mount siren designed for alarm signalling in demanding industrial, marine, and automation environments. This device operates at 24 V DC providing a loud 108 dB sound output measured at 1 meter, making it effective for alerting personnel in noisy workplaces and emergency situations.

The siren is constructed with a robust red polyamide housing and a corrosion-resistant powder-coated steel gong, ensuring reliability even in harsh conditions. Its IP66 rating protects against dust ingress and powerful water jets, suitable for outdoor and marine installations.

Installation is simplified by four M20 cable entry knockouts, allowing flexible loop-in, loop-out wiring. The surface mounting configuration ensures easy integration into existing setups.

Compliant with EN 50130-4:2011 alarm system standards and IEC 60533:1999 for shipboard installations, this siren meets rigorous quality and safety requirements. Operating temperature range from -25°C to +50°C further supports versatile use across various industrial sectors including fire trucks and mechanical automation.

Features include an anti-tamper gong bolt to prevent unauthorized alarm alteration and low power consumption for efficient operation. Its reliable performance under challenging environmental conditions makes it well suited for critical safety signalling.

This siren operates at 24 V DC with a current consumption of 470mA. Sound output of 108 dB at 1 meter ensures audible alert in industrial settings. Durable polyamide housing with corrosion-resistant steel gong. IP66 rating protects against dust and high-pressure water jets.

Four M20 cable entry knockouts for versatile cable installation. Complies with EN 50130-4:2011 and IEC 60533:1999 standards. Suitable for industrial, marine, and fire safety applications. Temperature operating range from -25°C to +50°C.

Energy-efficient design with low current consumption.

Choose Moflash A8BM Series Surface Mount Siren for reliable and robust audible alert signalling in a variety of industrial and hazardous locations. Explore more automation and signalling products at EnvMart for complete solutions.
