Huco Flexible Coupler Clamp Style Aluminium Hub, 28 mm Bore, 66 mm OD, 79 mm Length, 60 Nm Torque Rating, Model 592.66.5454

Huco 592.66.5454 Flexible Coupler is engineered for precision mechanical power transmission with excellent kinematic properties, using a clamp style shaft connection and aluminium hubs. This model features a 28 mm bore diameter and a total length of 79 mm, making it suitable for compact yet robust coupling requirements in various industrial machinery.

The stainless steel bellows construction provides flexibility to absorb torsional vibrations and accommodate axial, angular, and parallel misalignments, improving shaft alignment and reducing wear. It supports a maximum torque rating of 60 Nm and can operate effectively at speeds up to 8700 rpm, satisfying high-performance rotational requirements.

Designed to withstand operating temperatures from -30°C to 120°C, this flexible coupling is capable of functioning reliably in challenging thermal environments.

The clamp style assembly allows for straightforward shaft attachment, ensuring secure locking with an M8 screw size. This series, identified as Flex K, offers a fine balance between stiffness and flexibility, making it ideal for applications requiring precise torque transmission and compensation for shaft misalignment.

Common industrial applications include mechanical, fluid power, and power transmission systems in manufacturing, automotive, and processing machinery sectors. Its construction from aluminium and stainless steel ensures durability while minimizing weight.

Constructed with aluminium alloy hubs providing lightweight and durable performance. Features stainless steel bellows to accommodate torsional flexibility. Capable of handling a maximum torque rating of 60 Nm. Operating temperature range from -30°C to 120°C suitable for diverse industrial environments.

Supports maximum rotational speed of 8700 rpm, ensuring high-speed compatibility. Clamp style connection enables easy installation and secure shaft attachment. Designed to compensate for misalignments: 1.5° angular, 0.15 mm parallel, and 0.6 mm axial.

Bore sizes A and B both set at 28 mm for uniform shaft coupling. Series classified as Flex K, providing precision and kinematic performance. Uses M8 screw size in assembly for secure mounting. Consider exploring more flexible couplers and power transmission solutions in the Industrial Tools & Equipment Mechanical Machinery category on EnvMart.
