Weidmüller D-SERIES 4 Way 250V AC Panel Relay Socket 7760056107

Free Delivery in India | Lowest Global Shipping Charges

Weidmüller D-SERIES 4 Way 250V AC Panel Relay Socket 7760056107

Name: Weidmüller D-SERIES 4 Way 250V AC Panel Relay Socket 7760056107
Brand: Weidmuller
SKU: 268400
Price: 11.67 USD
Availability: InStock



Category Relay Socket Brand Weidmuller Condition New

Specifications

Country of Origin	China
Voltage	250V ac
Brand	Weidmüller
Current	10A
Mount Type	Panel
Series	D-SERIES
Terminal type	Screw
Standards/Approvals	cURus, EAC
Number of Contacts	4

Key Features

Operates at 250V AC and supports currents up to 10A.
Features a 4PDT contact configuration with 4 contacts.
Screw terminal type ensures secure wiring connections.
Compact size of 71mm height, 31mm width, and 29.5mm depth saves space.
Rated impulse withstand voltage of 4kV for surge protection.
Broad operating temperature range from -40°C to +70°C supports harsh environments.
IP10 rated for touch safety and protection against objects larger than 50mm.
Mounts easily on panels for convenient relay installation and replacement.

Product Description

Weidmüller 7760056107 D-SERIES 4 Way 250V AC Panel Relay Socket offers a reliable and compact solution for mounting relays in electrical and industrial control panels. This socket accommodates a 4PDT contact configuration with screw terminals, enabling secure and easy wiring connections. Its compact dimensions of 71mm height, 31mm width, and 29.5mm depth maximize panel space efficiency while providing robust electrical performance.

Designed to endure harsh industrial environments, the relay socket supports a broad temperature range from -40°C to +70°C and features a rated impulse withstand voltage of 4kV to protect against voltage surges. The IP10 rating ensures touch safety and guards against the ingress of objects larger than 50mm, making it suitable for varied industrial and commercial setups.

The socket accepts solid and finely stranded wires ranging from 0.5 to 2.5mm², as well as flexible wires with plastic collars and wire-end ferrules between 0.5 and 1.5mm², ensuring versatility in wiring options. This makes installation straightforward in manufacturing lines, automotive repair shops, and telecommunications equipment maintenance.

Mounting on panels is simple and efficient, allowing for quick installation, removal, and replacement of relays without complex rewiring, supporting faster maintenance and downtime reduction. This product is manufactured in China and complies with recognized standards including cURus and EAC approvals, ensuring quality and reliability.

Operates at 250V AC and 10A current rating. 4-way contact configuration with screw terminals. Compact dimensions for space-saving panel installations. Rated for 4kV impulse withstand voltage. Wide operating temperature range from -40°C to +70°C.

IP10 protective rating for safety and durability. Supports diverse wire sizes, including ferrule terminations. Suitable for manufacturing, automotive repair, and telecom uses. Manufactured in China with cURus and EAC certifications.
