ABB Molded Case Circuit Breaker 4-Pole 6.3A 65 kA Breaking Capacity Fixed Lever Thermal 1SDA067027R1 XT2N 160 TMD 6.3A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 6.3A 65 kA Breaking Capacity Fixed Lever Thermal 1SDA067027R1 XT2N 160 TMD 6.3A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067027R1 XT2N 160 TMD 6.3A FF
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	6.3A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	65kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	6.3 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Equipped with a thermal magnetic tripping mechanism for precise current interruption.
Fixed mounting and terminal type ensure robust installation and connectivity.
Rated for 690V AC and 500V DC with a frequency of 50/60 Hz.
Compact dimensions of 130mm height, 120mm width, and 82.5mm depth.
Features a user-friendly lever reset actuator type for easy operation.
Complies with CE, IEC, and RoHS standards guaranteeing safety and environmental compliance.
Designed and manufactured in Italy ensuring high build quality.

Product Description

ABB 1SDA067027R1 XT2N 160 TMD 6.3A FF Molded Case Circuit Breaker offers exceptional circuit protection with a 4-pole configuration and a rated current of 6.3 A. Designed for industrial and commercial electrical installations, it provides a breaking capacity of 65 kA suitable for demanding electrical environments. The breaker supports rated AC voltage up to 690V and DC voltage up to 500V with a rated frequency of 50/60 Hz for versatile applications.

This circuit breaker features a thermal magnetic tripping mechanism that ensures reliable and accurate interruption of overload and short circuit conditions, protecting electrical circuits and connected equipment. The fixed mounting and terminal design contribute to a sturdy and secure installation, making it ideal for use in electrical panels and switchgear.

Its compact size with dimensions of 130mm height, 120mm width, and 82.5mm depth allows easy integration into existing systems. The front-lever reset actuator enhances operational convenience, permitting quick reset after trip conditions.

Certified to CE, IEC, and RoHS standards, this product complies with international safety and environmental regulations. Originating from Italy, it reflects ABB's commitment to quality and durability.

Thermal magnetic tripping mechanism provides accurate overload and short circuit protection. Fixed mounting and terminal type enable secure installation. High breaking capacity of 65 kA suitable for industrial usage. Compatible with rated voltages of 690V AC and 500V DC.

Compact form factor for space-saving installations. Easy-to-use lever reset actuator. Certified to global safety and environmental standards.

This ABB Molded Case Circuit Breaker is applicable across industries including manufacturing, electrical distribution, automation, and HVAC systems. It is a critical component in ensuring safe and reliable operation of electrical networks.

For a broad selection of electrical protection devices including circuit breakers, explore the dedicated category on EnvMart to find compatible solutions from ABB and other top brands.
