SMC 3 Finger Double Acting Action Pneumatic Gripper Low Profile, Bore Diameter 12mm, Maximum Pressure 7 bar MHF2-12DR

SMC MHF2-12DR pneumatic gripper is a high precision, 3-finger double acting gripper with a low profile design that minimizes space usage and bending moments, enhancing accuracy and smooth operation. This model belongs to the MHF2 series, designed for reliable performance in industrial automation and pneumatic gripping tasks.

It features a bore diameter of 12mm and supports operation at a maximum pressure of 7 bar, making it suitable for a wide range of pneumatic actuator applications. The gripper can deliver a gripping force of 48N both internally and externally, ensuring a solid hold on objects.

This gripper offers three finger configuration, ideal for securely gripping various shapes, and includes an adjustable open width of 12mm with closed width also at 12mm, forming a compact gripping mechanism.

The device is equipped with an M5 port size for easy pneumatic hose connection and supports a maximum operating frequency of 120 cycles per minute to meet high-speed automation requirements. Operating temperature range from -10°C to 60°C allows it to function reliably across different industrial environments.

With compact dimensions (height 25mm, width 40mm, length 52mm) and a lightweight build of 155 grams, it provides an efficient and space-saving pneumatic gripping solution for manufacturing, assembly, robotics, and handling equipment.

The MHF2-12DR series also supports optional features such as adjustable stroke, auto switch capability, and use with NSF-H1 food grade lubricant options, enhancing versatility in various industrial and food processing applications.

Designed with a low profile to save space and reduce bending moments. Features double acting action for reliable gripping performance. Operates at a maximum pressure of 7 bar with a bore diameter of 12mm. Supports gripping force of 48N internally and externally for strong grip.

Constructed with durable materials, suitable for industrial automation use. Compact dimensions with height 25mm, width 40mm, and length 52mm. Operating temperature range from -10°C to 60°C for varied environments. Equipped with M5 port size for pneumatic connections.

Maximum operating frequency up to 120 cycles per minute for high-speed operation. Manufactured in Japan ensuring high quality standards.

Ideal for use in industrial automation, pneumatic tooling, assembly lines, robotics, and manufacturing processes requiring precise and repeatable gripping actions. Explore more pneumatic grippers and automation solutions in the Pneumatic Gripper category at EnvMart.
