Wurth Elektronik Common Mode Choke 168Ω Impedance 100MHz Test Frequency AEC-Q200 Compliant 782114075063
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | -55°C up to 140 °C |
| Height | 6.35mm |
| Depth | 12.7mm |
| Series | WE-TEFA |
| Maximum Operating Temperature | 140°C |
| Minimum Operating Temperature | -55°C |
| Test Frequency | 100MHz |
| Impedance | 168Ω |
| Standards/Approvals | RoHS, REACH |
| Automotive Standard | AEC-Q200 |
| In General for | Wires, Coaxial cables, Wire-wrapping cables, Multiconductor wires |
Key Features
- Ferrite core made of MgZn material for a wider frequency range than NiZn.
- Complies with the AEC-Q200 automotive standard for quality and durability.
- Suitable for wires, coaxial cables, wire-wrapping cables, and multiconductor wires.
- Supports on-board power supply and multimedia cable interfaces.
- RoHS and REACH compliant ensuring environmental safety.
- Operating temperature range from -55°C up to 140°C.
- Manufactured in China maintaining consistent quality standards.
Product Description
Wurth Elektronik 782114075063 Common Mode Choke offers excellent EMI suppression with a ferrite core made of MgZn, which performs effectively across a wider frequency range compared to traditional NiZn materials. This component is part of the WE-TEFA series and is engineered specifically for automotive and industrial use cases, ensuring dependable performance under harsh operating temperatures ranging from -55°C to 140°C.
The choke has an impedance of 168Ω tested at 100MHz, making it suitable for use on wires, coaxial cables, wire-wrapping cables, and multiconductor wires. It is also designed for on-board power supply lines and multimedia cable interfaces, catering to a variety of cable applications.
It meets the automotive standard AEC-Q200, guaranteeing quality and reliability in demanding environments. Additionally, this product follows the RoHS and REACH directives, highlighting its compliance with environmental and safety regulations.
Compact in size, with a depth of 12.7mm and height of 6.35mm, it offers flexibility for circuit board placement without compromising performance. Ferrite core made of MgZn material for wider frequency range performance. Adheres to AEC-Q200 automotive standard for demanding applications.
Applicable to various cables including coaxial and multiconductor wires. Supports on-board power supplies and multimedia cable interfaces. RoHS and REACH certified ensuring environmental compliance. Compact dimensions enable versatile installation options.
Operational temperature range from -55°C to 140°C for reliability. Manufactured to high-quality standards in China.
This common mode choke is optimal for industrial, automotive electronics, telecommunications, and signal filtering applications where suppression of electromagnetic interference is critical. It is a reliable component for PCB designs requiring EMI filters to enhance signal integrity and compliance with regulatory standards.
Explore the full range of Wurth Elektronik components and EMI filter solutions on EnvMart for quality assurance and comprehensive industrial electronics applications.
Explore more products in our Common Products category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The common mode choke has an impedance of 168Ω when tested at a frequency of 100MHz.
It operates within a temperature range of -55°C up to 140°C, making it suitable for various applications in harsh environments.
This common mode choke complies with the AEC-Q200 automotive standard, as well as RoHS and REACH directives for environmental safety.
The ferrite core is made of MgZn material, which allows for a wider frequency range performance compared to NiZn materials.
The choke has a height of 6.35mm and a depth of 12.7mm, allowing for flexible circuit board placement.
It is suitable for wires, coaxial cables, wire-wrapping cables, and multiconductor wires, making it versatile for various applications.
This model is designed for automotive and industrial applications, particularly for EMI suppression in power supply lines and multimedia cable interfaces.
It acts as an EMI filter, suppressing electromagnetic interference which helps enhance signal integrity in electronic circuits.
It is manufactured in China, adhering to consistent quality standards.
The common mode choke is tested at a frequency of 100MHz, which is critical for its performance in various applications.
Yes, it is RoHS and REACH compliant, ensuring it meets environmental safety regulations.
This model is part of the WE-TEFA series, which is engineered specifically for automotive and industrial use cases.
