ABB Tmax XT Molded Case Circuit Breaker 3-Pole 50A 690V AC Thermal Magnetic Tripping 1SDA067743R1 XT2S 160 TMG 50A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 50A 690V AC Thermal Magnetic Tripping 1SDA067743R1 XT2S 160 TMG 50A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067743R1 XT2S 160 TMG 50A FF
Depth	82.5mm
Width	90mm
Mount Type	Fixed
Current Rating	50A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	85kA
Number of Poles	3
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	50 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

The breaker has a fixed mounting type with front fixed terminals for secure connections.
Rated AC voltage capacity is 690V and DC voltage rating is 500V, suitable for various industrial applications.
It features a thermal magnetic (TMG) tripping mechanism to protect circuits from overloads and short circuits.
The device includes a lever-type reset actuator for easy manual operation.
Compact dimensions of 130mm height, 90mm width, and 82.5mm depth facilitate space-efficient installation.
Designed according to CE, IEC and RoHS standards, ensuring compliance and safety.
Better World compliant product designed for easy disassembly and environmental sustainability.
Rated frequency supports 50/60 Hz operation suitable for multiple electrical systems.

Product Description

ABB 1SDA067743R1 XT2S 160 TMG 50A FF is a Molded Case Circuit Breaker (MCCB) from the Tmax XT series, designed to provide high performance electrical protection with an interrupting capacity of 85 kA. It is a 3-pole device rated for 50 amperes and capable of operating at a rated AC voltage of 690 volts and rated DC voltage of 500 volts. This circuit breaker is ideal for industrial, commercial, and utility electrical panels to ensure safety and reliable operation by interrupting fault currents.

The breaker features a thermal magnetic tripping mechanism (TMG) which protects against both overload and short circuits. It comes with a fixed mounting type and front fixed terminals enabling sturdy and secure electrical connections. Operation is facilitated by a lever type reset actuator allowing quick manual resets after tripping events.

Its compact physical dimensions - height of 130mm, width of 90mm, and depth of 82.5mm - allow easy integration into panel setups where space is constrained. ABB ensures product compliance with CE, IEC, and RoHS standards, reflecting quality, safety, and environmental considerations. The breaker is also declared a Better World product, designed for disassembly to promote sustainability.

This MCCB supports both 50 and 60 Hz rated frequency ranges, making it suitable for use in a variety of global electrical infrastructure configurations, and is manufactured in Italy to strict quality controls.

The device provides reliable protection for electrical distribution systems against overload and short circuits. Its rugged construction and compliance with international standards make it suitable for industrial and manufacturing applications.

Compact design supports efficient use of panel space. Thermal Magnetic tripping mechanism offers dual protection functionality. Easy reset functionality ensures minimal downtime during maintenance. Rated for AC and DC voltages to cover a broad range of electrical systems.

Better World certification highlights sustainability credentials in design and materials.

This ABB Molded Case Circuit Breaker is a suitable choice for electrical and automation professionals looking for a durable and compliant protective device capable of safeguarding circuits in industrial environments.
