ABB Tmax XT Molded Case Circuit Breaker 4-Pole 160A, Breaking Capacity 200 kA, Fixed 1SDA067713R1 XT2V 160 TMA 160A 3P+N FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 160A, Breaking Capacity 200 kA, Fixed 1SDA067713R1 XT2V 160 TMA 160A 3P+N FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067713R1 XT2V 160 TMA 160A 3P+N FF
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	160A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	200kA
Number of Poles	4
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	160 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Designed for industrial and commercial electrical protection applications.
Offers rated AC voltage of 690 V and DC voltage of 500 V.
Features fixed front terminals for secure connections.
Conforms to RoHS, IEC, and CE standards ensuring safety and compliance.
Thermal magnetic tripping mechanism protects circuits effectively.
Reset actuator lever facilitates easy manual reset after tripping.
Includes 4 poles suitable for multi-phase systems.
Rated impulse withstand voltage of 8 kV for surge protection.

Product Description

ABB 1SDA067713R1 XT2V 160 TMA 160A 3P+N FF Molded Case Circuit Breaker (MCCB) is a robust 4-pole device designed for industrial, commercial, and electrical automation protection applications. Rated for a current capacity of 160 A, it offers a high breaking capacity of 200 kA, suitable for demanding electrical circuit protection tasks.

This MCCB is fixed mounted and equipped with thermal magnetic tripping mechanism that provides reliable overload and short circuit protection. The front fixed terminals facilitate secure and maintenance-friendly connections.

The breaker is rated for 690 V AC and 500 V DC, making it versatile for AC and DC systems. Its compact form factor has dimensions of 130 mm height, 120 mm width, and 82.5 mm depth, allowing it to fit into various panel designs.

Compliant with RoHS, IEC, and CE standards, this ABB product ensures environmental safety and regulatory compliance. It also features a reset lever actuator for easy re-engagement after trip events.

The rated impulse withstand voltage of 8 kV provides robust surge protection, enhancing device longevity and system stability. Being made in Italy, the product reflects high manufacturing quality and reliability.

This MCCB is suitable for industrial automation, building electrical panels, HVAC controls, manufacturing equipment protection, and other commercial power distribution systems requiring high-performance circuit breakers.

Designed for industrial and commercial electrical applications. 4 poles with 160 A rated current ensure effective multi-phase circuit protection. Thermal magnetic trip mechanism for accurate overload and short circuit protection.

Fixed mounting with front terminals for reliable installation. Compact design with 130mm height, 120mm width, and 82.5mm depth. Conforms to RoHS, IEC, and CE standards. Rated AC voltage 690 V and DC voltage 500 V for versatile usage.

Rated impulse withstand voltage of 8 kV safeguards against surges. Reset lever actuator for easy manual reset after tripping. Manufactured in Italy delivering quality assurance. Discover more industrial and electrical protection devices like this ABB Molded Case Circuit Breaker in the Electronics & Electricals category at EnvMart.
