ABB Tmax XT Molded Case Circuit Breaker 3-Pole 3.2A 150kA Breaking Capacity Fixed 1SDA067631R1 XT2L 160 TMD 3.2A FF

ABB 1SDA067631R1 XT2L 160 TMD 3.2A FF Molded Case Circuit Breaker offers optimal circuit protection for industrial and commercial electrical installations. Designed for 3-pole operation with a thermal magnetic tripping mechanism, it is capable of breaking currents up to 150 kA and supports a rated current of 3.2 A. The breaker operates at rated AC voltage of 690 V and DC voltage of 500 V, making it suitable for diverse power distribution applications.

This device features fixed mounting and front terminals to facilitate secure and stable installation within electrical panels. With compact dimensions - 130 mm height, 90 mm width, and 82.5 mm depth - it fits efficiently within constrained spaces. The lever-type reset actuator ensures easy manual control of the breaker during maintenance or fault clearance.

Manufactured to comply with IEC, RoHS, and CE standards, this ABB Molded Case Circuit Breaker ensures compliance with international safety and environmental quality norms. Rated impulse withstand voltage of 8 kV provides robust resistance to electrical surges, and the device supports operation at a rated frequency of 50/60 Hz, compatible with global power grids.

As a Better World product designed for disassembly, this breaker enables environmentally responsible end-of-life management. It is engineered in Italy, reflecting ABB's commitment to quality and innovation. Its thermal magnetic technology protects circuits by detecting overload and short circuit conditions with high precision.

Typical applications include industrial electrical distribution, manufacturing facilities, commercial installations, and HVAC systems where reliable circuit protection is critical. This MCCB ensures operational safety, maintains system integrity, and reduces downtime caused by electrical faults.

Rated current of 3.2 A with a rated uninterrupted current of 160 A. Supports rated AC voltage up to 690 V and rated DC voltage up to 500 V. Equipped with a lever-type reset actuator for ease of operation. Compact dimensions with height 130 mm, width 90 mm, and depth 82.5 mm.

Designed following IEC, RoHS, and CE standards ensuring high safety and quality. Thermal magnetic tripping mechanism provides reliable protection against overload and short circuits. Fixed mounting and terminal types suitable for stable installation.

Better World product designation with a design for disassembly to support sustainability. Rated impulse withstand voltage of 8 kV to handle transient surges. Operates efficiently at rated frequency of 50/60 Hz. Explore the full range of ABB circuit breakers and electrical protection devices on EnvMart to find solutions tailored for your industrial and commercial applications.
