ABB Molded Case Circuit Breaker 4-Pole 80A 690V AC Rated Voltage 5kA Breaking Capacity Fixed Mount XT1H

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 80A 690V AC Rated Voltage 5kA Breaking Capacity Fixed Mount XT1H



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT1H
Brand	ABB
Height	130mm
Model	XT1H
Depth	70mm
Width	101.6mm
Mount Type	Fixed
Current Rating	80A
Series	1SDA06
Terminal type	Screw
Breaking Capacity	5kA
Number of Poles	4
Standards/Approvals	IEC
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Break Time	Instantaneous
Short circuit performance level	H

Key Features

This MCCB has a rated AC voltage of 690V and rated DC voltage of 500V to support diverse industrial environments.
It features a breaking capacity of 5 kA ensuring reliable short circuit interruption.
The device comes with four poles and is designed for fixed mounting applications.
Its terminal type is screw, providing secure electrical connections.
Compact physical dimensions with a height of 130mm, width of 101.6mm, and depth of 70mm.
Complies with IEC standards and meets high short circuit performance level rating H.
The MCCB has instantaneous break time for rapid circuit disconnection.
Manufactured in Italy ensuring premium quality and reliability.

Product Description

ABB XT1H 1SDA067459R1 XT1H 160 TMD 80A FF Molded Case Circuit Breaker is a high-performance electrical protection device designed to safeguard power distribution systems in industrial, commercial, and manufacturing environments.

This 4-pole MCCB is rated at 80 amperes with a 690V AC rated voltage and 500V DC rated voltage, providing robust protection under varied electrical conditions. The breaker exhibits a breaking capacity of 5 kA, ensuring it can safely interrupt high fault currents without damage, critical in maintaining electrical safety.

Designed for fixed mounting, this circuit breaker features screw terminals for secure and ease of wiring during installation and maintenance. The compact yet durable physical dimensions - 130mm height, 101.6mm width, and 70mm depth - allow it to be integrated into standard electrical panels and switchgear.

Certified under IEC standards and rated with short circuit performance level H, it guarantees compliance and reliability for industrial and commercial electrical installations. Its instantaneous break time capability enhances response to electrical faults, reducing the risk of damage to connected equipment and increasing system uptime.

Manufactured in Italy, this model ensures high-quality workmanship and materials suited for demanding electrical applications. This MCCB has a rated AC voltage of 690V and DC voltage of 500V. Breaking capacity is rated at 5 kA for effective fault interruption.

Four-pole design ensures comprehensive electrical protection. Fixed mount type with screw terminal connections. Physical dimensions: 130mm (H) x 101.6mm (W) x 70mm (D). Instantaneous break time for fast circuit disconnection.

Conforms to IEC standards with short circuit performance level H.

This Molded Case Circuit Breaker is suitable for electrical and automation applications, panel building, manufacturing, commercial electrical distribution, and industrial infrastructure projects.

Explore the full range of ABB MCCBs and circuit protection products to find solutions that meet your power system needs at EnvMart.
