ABB Molded Case Circuit Breaker 4-Pole 80A Breaking Capacity 4 kA Fixed Mount 690V AC 500V 1SDA067405R1 XT1C 160 TMD 80A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 80A Breaking Capacity 4 kA Fixed Mount 690V AC 500V 1SDA067405R1 XT1C 160 TMD 80A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067405R1 XT1C 160 TMD 80A FF
Depth	70mm
Width	101.6mm
Mount Type	Fixed
Current Rating	80A
Series	1SDA06
Terminal type	Screw
Breaking Capacity	4kA
Number of Poles	4
Standards/Approvals	IEC
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Break Time	Instantaneous
Rated current (In)	80 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

This MCCB features a fixed mounting type suitable for various electrical installations.
It operates with a rated AC voltage of 690V and DC voltage of 500V.
Equipped with front screw terminals for secure wiring connections.
Designed with a thermomagnetic release type for precise breaking response.
The breaker dimensions are 101.6mm width, 130mm height, and 70mm depth.
It complies with IEC standards assuring quality and safety.
Offers instantaneous break time for rapid fault clearance.
Originating from Italy, it ensures European manufacturing standards.

Product Description

The ABB 1SDA067405R1 XT1C 160 TMD 80A FF Molded Case Circuit Breaker is a four-pole device designed for industrial and commercial electrical protection applications. Rated for 80 amperes, it offers a robust breaking capacity of 4 kiloamperes, ensuring effective interruption of fault currents to safeguard electrical circuits.

This MCCB features a fixed mount type with screw terminals on the front, facilitating reliable and secure electrical connections. The thermomagnetic release mechanism provides defined tripping characteristics, combining thermal overload protection with instantaneous magnetic trip for short-circuit conditions.

Operating at a rated AC voltage of 690 volts and rated DC voltage of 500 volts, it is suitable for diverse power system applications including industrial distribution boards, motor protection, and electrical automation systems.

Measuring 101.6 mm in width, 130 mm in height, and 70 mm in depth, this compact circuit breaker fits standard industrial panel configurations while maintaining performance. The product strictly adheres to IEC standards, guaranteeing compliance with international electrical safety and performance requirements.

Its instantaneous breaking time ensures rapid disconnection during fault conditions, reducing potential damage and enhancing operational safety. Manufactured in Italy, this product reflects ABB's commitment to high-quality engineering and durable components.

This MCCB features a fixed mounting type suitable for various electrical installations. It operates with a rated AC voltage of 690V and DC voltage of 500V. Equipped with front screw terminals for secure wiring connections.

Designed with a thermomagnetic release type for precise breaking response. The breaker dimensions are 101.6mm width, 130mm height, and 70mm depth. It complies with IEC standards assuring quality and safety. Offers instantaneous break time for rapid fault clearance.

Originating from Italy, it ensures European manufacturing standards.

This ABB Molded Case Circuit Breaker is ideal for industrial, manufacturing, electrical panel, and automation system applications requiring reliable circuit protection and fault current interruption.
