ABB Molded Case Circuit Breaker 4-Pole 160A, Breaking Capacity 150 kA, Fixed Mount XT4L 1SDA06

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 160A, Breaking Capacity 150 kA, Fixed Mount XT4L 1SDA06



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT4L
Brand	ABB
Height	160mm
Model	XT4L
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	160A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	4
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Short circuit performance level	L

Key Features

The unit features solid state tripping mechanism for reliable protection.
Rated AC voltage is 690V, suitable for industrial electrical use.
Compact dimensions with height 160mm, width 140mm, and depth 82.5mm.
The device includes a lever reset actuator for easy operation.
Complies with RoHS, IEC, and CE standards ensuring quality and safety.
Manufactured in Italy following Better World sustainability guidelines.
Designed for front terminal fixed installation providing secure connection.
Short circuit performance level L offers robust protection in demanding environments.

Product Description

ABB XT4L Molded Case Circuit Breaker 4-Pole 160A with Breaking Capacity of 150 kA is engineered for demanding industrial electrical protection. It features a fixed mount design with front terminals, rated for 690 Vac operational voltage and 1000 V insulation voltage (Ui), ensuring high safety margins.

This breaker utilizes a solid state tripping mechanism, specifically the AC Ekip LS/I release type, for precise and reliable circuit protection. The compact construction with dimensions 160mm height, 140mm width, and 82.5mm depth supports space-efficient panel integration.

Key operational benefits include the lever-style reset actuator which allows quick manual resetting after fault clearance. Certified under RoHS, IEC, and CE standards, this device meets rigorous environmental and safety regulations. Manufactured in Italy, it embodies advanced engineering and quality manufacturing.

This molded case circuit breaker is suitable for industrial, commercial, and utility electrical distribution applications requiring 160A current rating and high breaking capacity. Its design aligns with Better World principles focusing on disassembly and sustainability.

The breaker has 4 poles for three-phase circuit protection with neutral. Rated for 690V AC operational voltage and fixed terminal connection. Breaking capacity of 150 kA provides high fault current interruption capability.

Solid state tripping mechanism ensures fast, reliable response to electrical faults. Compact dimensions facilitate easy mounting in electrical panels. Lever reset actuator simplifies operation and maintenance. Compliance with international standards assures safety and reliability.

Designed for sustainability with Better World claims and disassembly features.

Explore the ABB XT4L series for high-quality Molded Case Circuit Breakers suitable for robust electrical protection in industrial environments. This product is part of EnvMart's Electronics & Electricals category offering reliable and certified circuit protection solutions.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The breaking capacity of this molded case circuit breaker is 150 kA, providing high fault current interruption capability.

The current rating of the ABB XT4L model is 160A, suitable for various industrial electrical applications.

This circuit breaker has compact dimensions of 160mm in height, 140mm in width, and 82.5mm in depth.

It utilizes a solid state tripping mechanism, specifically the AC Ekip LS/I release type, for reliable circuit protection.

Yes, it complies with RoHS, IEC, and CE standards, ensuring it meets rigorous environmental and safety regulations.

The rated AC voltage for this circuit breaker is 690V, making it suitable for industrial electrical use.

The lever reset actuator allows for quick manual resetting of the circuit breaker after a fault has been cleared, simplifying operation and maintenance.

This model features a fixed mount design with front terminals for secure connection.

This molded case circuit breaker has 4 poles, providing protection for three-phase circuits with a neutral.

This circuit breaker is manufactured in Italy, adhering to advanced engineering and quality manufacturing practices.

The short circuit performance level of this unit is classified as L, offering robust protection in demanding environments.

This model is designed for disassembly and follows Better World sustainability guidelines, focusing on environmental responsibility.
