ABB Molded Case Circuit Breaker 4-Pole 63A 100kA Breaking Capacity Fixed Terminals XT4H 1SDA068547R1 Italy

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 63A 100kA Breaking Capacity Fixed Terminals XT4H 1SDA068547R1 Italy



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT4H
Brand	ABB
Height	160mm
Model	XT4H
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	63A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	100kA
Number of Poles	4
Standards/Approvals	RoHS, IEC, CE
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Short circuit performance level	H

Key Features

Designed with fixed terminals and mounting for secure installation.
Rated operational AC voltage is 690V with insulation voltage of 1000V.
Equipped with solid state tripping mechanism for precise protection.
Certified to RoHS, IEC and CE standards ensuring safety and compliance.
Features a lever type reset actuator for ease of operation.
Manufactured in Italy with a short circuit performance level H.

Product Description

ABB XT4H 1SDA068547R1 Molded Case Circuit Breaker is a 4-pole fixed mounting device designed for industrial and commercial electrical protection applications. This circuit breaker has a rated current of 63 Amperes and offers a high breaking capacity of 100 kA, ensuring system safety under fault conditions.

The breaker supports a rated AC operational voltage of 690 V and insulation voltage of 1000 V, suitable for high power electrical circuits, guaranteeing robust performance. Featuring a solid state Ekip LSIG tripping mechanism, the device provides accurate trip characteristics to protect against overload and short circuit events effectively.

The compact dimensions (160 mm height, 140 mm width, and 82.5 mm depth) allow easy integration into electrical panels with limited space. It includes a lever type reset actuator allowing quick manual reset post-trip. Manufactured in Italy, this product complies with internationally recognized standards including RoHS, IEC, and CE, assuring high-quality and safety standards.

Designed with fixed terminals for secure electrical connections. 4-pole configuration suitable for three-phase power systems. High breaking capacity of 100 kA supports heavy-duty industrial usage. Solid state release mechanism enhances tripping accuracy under different fault conditions.

Compact size aids in space-constrained installations. Certified for international safety and environmental standards. Easy to operate with lever reset actuator.

This ABB Molded Case Circuit Breaker is ideal for usage in industrial automation, manufacturing plants, electrical panels, and commercial electrical setups requiring reliable circuit protection.

Explore more high-quality circuit protection devices on EnvMart to ensure safety and efficiency in your electrical infrastructure.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This molded case circuit breaker has a breaking capacity of 100 kA, ensuring it can handle heavy-duty industrial usage under fault conditions.

The rated current for this model is 63 Amperes, making it suitable for various electrical protection applications.

The dimensions of this circuit breaker are 160 mm in height, 140 mm in width, and 82.5 mm in depth, allowing for easy integration into electrical panels with limited space.

It features a solid state tripping mechanism, which provides accurate trip characteristics for protection against overload and short circuit events.

The rated operational AC voltage for this circuit breaker is 690 V, making it suitable for high power electrical circuits.

Yes, it is certified to RoHS, IEC, and CE standards, ensuring safety and compliance with international regulations.

This model includes a lever type reset actuator, allowing for quick manual reset after a trip event.

This circuit breaker has a 4-pole configuration, making it suitable for three-phase power systems.

It is manufactured in Italy, ensuring adherence to high-quality production standards.

This unit is designed for fixed mounting, providing secure installation in electrical systems.

The insulation voltage for this circuit breaker is rated at 1000 V, which supports its application in high voltage environments.

This circuit breaker is ideal for industrial automation, manufacturing plants, and commercial electrical setups requiring reliable circuit protection.
