Schneider Electric ComPact NSXm Molded Case Circuit Breaker 4-Pole 125A 50kA Breaking Capacity DIN Rail LV426418

Schneider Electric LV426418 ComPact NSXm Molded Case Circuit Breaker is a high-performance 4-pole electrical protection device rated at 125A with a breaking capacity of 50 kiloamperes. This MCCB series is the smallest in the ComPact NSXm range, designed to provide robust circuit protection from 16 to 160 amperes. Its compact construction makes it ideal for industrial, commercial, and electrical automation applications where space efficiency and reliability are critical.

The breaker features a thermal magnetic tripping mechanism with Type D tripping characteristics, ensuring quick response to overload and short-circuit conditions. It is intended for mounting on standard DIN rails, facilitating streamlined panel assemblies and ease of installation. The screw terminal type secures conductor connections firmly against vibration and thermal cycling.

Rated at 690 V AC, this circuit breaker complies with global standards including CCC, CE, EAC, EN, IEC, and RoHS, guaranteeing quality and environmental safety. The toggle switch actuator enables straightforward manual operation and reset functionality.

Dimensionally, it measures 137 mm in height and depth, with a width of 80 mm, making it suitable for compact distribution boards and switch panels. Compact NSXm series supports a wide current range from 16 to 160 A for versatile protection.

Four-pole design enables three-phase circuit protection plus neutral. Thermal magnetic tripping mechanism with Type D characteristic ensures reliable overload and short circuit protection. DIN rail mount facilitates easy and secure panel installation.

Rated for 690 V AC operation, complying with international safety and performance standards. Screw terminals provide secure and durable electrical connections. Toggle switch actuator for easy manual operation and resetting.

Compliance with CCC, CE, EAC, EN, IEC and RoHS standards supports global use. Compact physical dimensions allow fitting into space-constrained environments.

This Molded Case Circuit Breaker is suitable for use in electrical distribution, automation control panels, manufacturing plants, industrial facilities, and other applications requiring dependable circuit protection. Schneider Electric's reputation ensures excellent build quality and reliable operation for your electrical systems. Browse the Electronics & Electricals category on EnvMart for more solutions from trusted brands like Schneider Electric.
