Schneider Electric ComPact NSXm Molded Case Circuit Breaker 4-Pole 100A 20kA Thermal Magnetic Toggle Switch LV426227
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426227 |
| Depth | 137mm |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 100A |
| Series | NSXm |
| Terminal type | Screw |
| Breaking Capacity | 20kA |
| Number of Poles | 4 |
| Standards/Approvals | CCC, EAC, CE, RoHS, IEC, EN |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Mount Hole Size | 4.5 mm |
Key Features
- Compact NSXm series suitable for applications from 16 to 160 A.
- Rated AC voltage of 690 V AC ensuring wide industrial compatibility.
- Toggle switch actuator for easy manual reset.
- Tripping characteristic Type D for selective short circuit protection.
- Screw terminal type for secure electrical connections.
- Complies with CCC, EAC, CE, RoHS, IEC, and EN standards for quality and safety.
- Mount hole size of 4.5 mm for robust installation.
Product Description
Schneider Electric LV426227 ComPact NSXm Molded Case Circuit Breaker 4-Pole 100A is designed for industrial and commercial electrical protection, offering superior reliability and compact size.
This circuit breaker features a thermal magnetic tripping mechanism with Type D tripping characteristics, enabling selective short circuit and overload protection. Rated for a high breaking capacity of 20 kA at 690 V AC, it handles significant electrical faults effectively, ensuring system safety.
The compact design supports DIN Rail mounting with precise dimensions: 137mm height, 137mm depth, and 80 mm width. Screw terminals provide secure and reliable electrical connections while the toggle switch actuator allows for straightforward manual resets during maintenance or fault clearing.
Built to meet stringent international standards including CCC, EAC, CE, RoHS, IEC, and EN, this circuit breaker is suitable for diverse industrial environments. The ComPact NSXm range accommodates currents from 16 to 160 A, with this model rated at 100 A for medium scale applications.
Compact NSXm series suitable for applications from 16 to 160 A. Rated AC voltage of 690 V AC ensuring wide industrial compatibility. Toggle switch actuator for easy manual reset. Tripping characteristic Type D for selective short circuit protection.
Dimensions ensure convenient DIN Rail mounting: 137mm height, 137mm depth, 80mm width. Screw terminal type for secure electrical connections. Complies with CCC, EAC, CE, RoHS, IEC, and EN standards for quality and safety.
Mount hole size of 4.5 mm for robust installation.
This product is ideal for use in industrial automation, electrical distribution panels, manufacturing plants, and commercial constructions requiring dependable circuit protection. Its compact size combined with high-performance attributes ensures minimal space usage without compromising safety.
Explore more from the ComPact NSXm range and Schneider Electric electrical solutions on EnvMart for reliable circuit breaker and automation products.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 100A, making it suitable for medium scale applications.
It has a breaking capacity of 20 kA, allowing it to handle significant electrical faults effectively.
The dimensions are 137mm in height, 137mm in depth, and 80mm in width, which supports convenient DIN Rail mounting.
It supports DIN Rail mounting, ensuring easy installation in electrical distribution panels and industrial automation systems.
The rated AC voltage is 690 V AC, ensuring compatibility with a wide range of industrial applications.
It features Type D tripping characteristics, which provide selective short circuit protection.
It uses screw terminals for secure and reliable electrical connections.
The reset actuator type is a toggle switch, allowing for easy manual resets during maintenance or fault clearing.
It complies with CCC, EAC, CE, RoHS, IEC, and EN standards, ensuring quality and safety in its applications.
The mount hole size is 4.5 mm, facilitating robust installation in various environments.
It is ideal for use in industrial automation, electrical distribution panels, manufacturing plants, and commercial constructions.
This model belongs to the ComPact NSXm series, which is suitable for applications ranging from 16 to 160 A.
