Schneider Electric Molded Case Circuit Breaker 4-Pole 32A Breaking Capacity 16kA DIN Rail LV426122
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426122 |
| Depth | 137mm |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 32A |
| Series | NSXm |
| Terminal type | Screw |
| Breaking Capacity | 16kA |
| Number of Poles | 4 |
| Standards/Approvals | RoHS, IEC, EN, EAC, CE, CCC |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Mount Hole Size | 4.5 mm |
Key Features
- Compact NSXm range design suitable for 16 to 160 A applications.
- Four poles provide comprehensive circuit protection.
- Rated AC voltage of 690V ac for high voltage systems.
- Screw terminal type ensures secure electrical connections.
- Toggle switch reset actuator promotes easy operation.
- Type D tripping characteristic offers selective circuit interruption.
- Thermal magnetic tripping mechanism safeguards against overload and short circuits.
- Conforms to multiple standards including RoHS, IEC, EN, EAC, CE, and CCC.
Product Description
Schneider Electric LV426122 Molded Case Circuit Breaker 4-Pole 32A is part of the ComPact NSXm series, designed for reliable circuit protection in industrial and commercial electrical installations. This MCCB features a breaking capacity of 16 kA and supports DIN rail mounting for convenient integration into control panels.
With a compact design capable of handling current ratings from 16 to 160 A, it suits diverse applications requiring robust overload and short circuit protection. The device utilizes a thermal magnetic tripping mechanism with Type D characteristics, ensuring rapid disconnection during electrical faults.
The breaker operates at a rated AC voltage of 690V ac and is equipped with screw terminals for secure wiring. The toggle switch reset actuator facilitates straightforward manual operation and resetting after tripping.
Physical dimensions include a height of 137mm, depth of 137mm, and width of 80mm, making it fit well in standard DIN rail enclosures. Compliance with industry standards such as RoHS, IEC, EN, EAC, CE, and CCC guarantees quality and safety assurance.
Compact design suitable for industrial electrical control systems. Four-pole configuration for comprehensive circuit interruption. Breaking capacity of 16 kA ensures reliable fault clearing. Screw terminal connections for durability and ease of installation.
Thermal magnetic tripping with Type D characteristics for optimal protection. Rated for 690V ac applications in varied environments. Toggle switch actuator enables simple resetting of the breaker. Certifications attained include RoHS, IEC, EN, EAC, CE, and CCC.
This Molded Case Circuit Breaker is ideal for industrial, manufacturing, and commercial electrical distribution systems where dependable overload and short circuit protection is vital. It integrates easily on DIN rails within electrical panels and switchboards.
Explore Schneider Electric products and other circuit breakers at EnvMart for advanced electrical safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this model is 16 kA, ensuring reliable fault clearing during electrical faults.
It operates at a rated AC voltage of 690V ac, suitable for high voltage applications.
This unit features a 4-pole configuration, providing comprehensive circuit interruption.
The dimensions are 137mm in height, 137mm in depth, and 80mm in width, making it compatible with standard DIN rail enclosures.
It utilizes a thermal magnetic tripping mechanism, which safeguards against overload and short circuits.
The circuit breaker has Type D tripping characteristics, which provide selective circuit interruption.
It features screw terminal connections, ensuring secure and durable electrical connections.
Yes, it conforms to multiple standards including RoHS, IEC, EN, EAC, CE, and CCC, ensuring quality and safety assurance.
The current rating for this model is 32A, suitable for various industrial and commercial applications.
It is designed for DIN rail mounting, allowing for convenient integration into control panels.
This circuit breaker is manufactured in India.
It is ideal for industrial, manufacturing, and commercial electrical distribution systems requiring reliable overload and short circuit protection.
